Cheap Liquid Pressure Sensor With Voltage Output

Supply Voltage

8-35V &  5V

Supply Current

6 mA Max

Output Voltage

Electric Connector

4 to 20mA,  0 to 10V, 0.5 to 4.5V

Hirschmann / Parkard / Direct Cable / Special

Range

Pressure  Type

Measure Media

0 to -1,1,2,3..600bar

A, G

Water, Air, Oil

Proof Pressure

200%FS

Total Accuracy (%FS) ¹

Long Term Stability

Response Time

0.5%FS &1.0%FS

0.3%FS/year (max.)

1ms (typ.)

Operating Temperature Range

-40°C to +125°C

Storage Temperature Range

-40°C to +150°C

Protection Class

Material

IP 65

304L Stainless Steel

Pressure Port

NPT 1/8, NPT 1/4, G1/4, G1/8 Customize
