Bourdon Tube Pressure Gauge Type 111.10DW

Xian Wellwork Industrial Co., Ltd.

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Germany

Model Number:

111.10DW

Payment & Shipping

Payment Methods:

Port of Shipment:

Xi'an

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Germany

Model Number 111.10DW

General Specifications

Bourdon Tube Pressure Gauge Type 111.10DW,

Black Plastic Drinking Water Series - Lower Mount

Applications

Safe for applications where water is anticipated to be used for human consumption
For applications in which products must comply with the 2014 US Safe Drinking Water Act and NSF 61/372

Special features

Brass wetted parts with lead content ≤0.25%.
NSF/ANSI 61 listed and certified to NSF/ANSI 372 and conforms with the lead content requirements for lead-free plumbing as defined by California, Vermont, Maryland, and Louisiana state laws and the U.S. Safe Drinking Water Act

Standard Features

Design EN837-1 and ASME B40.100	Bourdon Tube Material: Lead-free copper alloy
Sizes 2", 2½" and 4" (50, 63, and 100 mm)	Solder No-lead solder
Accuracy class +3/2/3% of span (ASME B40.100 Grade B)	Movement Copper alloy
Ranges (All ranges not stocked) Vacuum/Compound to 30" Hg / 0 / 200 psi Pressure from 15 psi to 600 psi or other equivalent units of pressure or vacuum (Drinking water applications typically do not exceed 300 psi)	Dial White plastic with stop pin (2", 2½") White aluminum with stop pin (4")
Working pressure Steady: 3/4 of full scale value Fluctuating: 2/3 of full scale value Short time: full scale value	Pointer Black ABS plastic (2", 2½" LM) Black aluminum (4" LM)
Operating temperature Ambient: -40°F to 140°F (-40°C to 60°C) Media: 140°F (+60°C) maximum	Case Black plastic
Temperature error Additional error when temperature changes from reference temperature of 68°F (20°C) +0.4% for every 18°F (10°C) rising or falling. Percentage of span.	Window Clear plastic, snap-fit
Pressure connection Material: Lead-free copper alloy (lead content ≤0.25%) Lower mount (LM) 1/4" NPT
