Standard National Railway Steel Rail

Fujian Fenan Aluminium Co., Ltd.
Standard National Railway Steel Rail thumbnail-1
Standard National Railway Steel Rail thumbnail-2
Standard National Railway Steel Rail thumbnail-3
Standard National Railway Steel Rail thumbnail-4
Standard National Railway Steel Rail thumbnail-5
Standard National Railway Steel Rail thumbnail-6
Standard National Railway Steel Rail photo-1
Standard National Railway Steel Rail photo-2
Standard National Railway Steel Rail photo-3
Standard National Railway Steel Rail photo-4
Standard National Railway Steel Rail photo-5
Standard National Railway Steel Rail photo-6
US$ 656 - 866 MOQ: 3 Tons
Key Specifications
Get Latest Price
Standard:
AISI, ASTM, BS, DIN, GB, JIS
Grade:
55Q,Q235,45Mn,50Mn
Rail Heigth:
63.00mm-114.00mm
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
fuzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Standard AISI, ASTM, BS, DIN, GB, JIS
Grade 55Q,Q235,45Mn,50Mn
Rail Heigth 63.00mm-114.00mm
Bottom Width 63.00mm-114.00mm
Web Thickness 5.90-17.00mm
Head Width 25.00-68.00mm
Length as your requirement
Place of Origin Fujian, China
Brand Name FENAN
Model Number Standard national railway steel rail
Type Light Rail
Application Railway Rail
Weight 8.94KG/M2-51.514KG/M2
Secondary Or Not Non-secondary
Bolt Hole Diameter 22mm 24mm

Product:  Standard national railway steel rail



key words:  Standard national railway steel rail



Extruded aluminum rails size

Light rail

Size

Kg/m

Height (mm)

Bottom width

(mm)

Head width

(mm)

Middle thickness

(mm)

Length

(m)

Weight (kg/m)

Standard

5

50

44

22

4.5

5-10

5.03

YB

8

65

54

25

7

5-10

8.42

YB

11

80.5

66

32

7

6-10

11.2

YB

15

91

76

37

7

6-12

14.72

YB

18

90

80

40

10

7-12

18.06

YB

24

107

92

51

10.9

7-12

24.46

YB

9

63.50

63.50

32.10

5.90

5-7

8.94

GB

12

69.85

69.85

38.10

7.54

6-10

12.20

GB

15

79.37

79.37

42.86

8.33

6-10

15.20

GB

22

93.66

93.66

50.80

10.72

7-10

22.30

GB

30

107.95

107.95

60.33

12.30

7-10

30.10

GB

Heavy rail

Size

Kg/m

Height (mm)

Bottom width

(mm)

Head width

(mm)

Middle thickness

(mm)

Length

(m)

Weight (kg/m)

Standard

33

120

110

60

12.5

12.5

33.286

GB

38

134

114

68

13

12.5-25

38.733

GB

43

140

114

70

14.5

12.5-25

44.653

GB

50

152

132

70

15.5

12.5-25

51.514

GB

60

176

150

73

16.5

9-12.5,25



GB

Crane rail

Size

Height (mm)

Bottom width

(mm)

Head width

(mm)

Middle thickness

(mm)

Length

(m)

Weight (kg/m)

Standard

QU70

120

120

70

28

12

52.8

GB

QU80

130

130

80

32

12

81.13

GB

QU100

150

150

100

38

12

113.32

GB

QU120

170

170

120

44

12

150.44

GB

































































if you are interesting in, pls contact: Ms. Sarah (skype : sarahshang88 )



product photos:

Standard national railway steel railStandard national railway steel railStandard national railway steel railStandard national railway steel railStandard national railway steel railStandard national railway steel railStandard national railway steel railStandard national railway steel railStandard national railway steel railStandard national railway steel railStandard national railway steel rail



Standard national railway steel rail

Standard national railway steel railStandard national railway steel railStandard national railway steel rail
