Specifications
aluminum frame1.6063/6005 T5/T6
2.Mill finish, powder coated,anodized,electrophoretic
3.Capacity: 3000 ton/Month
[Popular]window anodize profile aluminum frame 6063
Low prices always accompany with high risk, maybe quality, quantity or reputation.
Our company FUJIAN FENAN ALUMINIUM CO., LTD is one of the biggest manufacturer of the aluminium extrusion for window, doors, industrial, tupe, pipe, light tool, and so on .The factory located in FUZHOU city covers 140000sq meters with about 1000 workers .We have done the aluminium business since 1988 years .We have ourself factoy, Design depart. QC, Sales Term.Our capacity is 6000 tons per month.
- Material:6063/6063A/6065/6061/6043 with T5/T6
- Surface treatment :Mill finish/anodize/powder coating /wood-grained/Electripoese.
- Certification:ISO9001/14004;OHSAS18001
- Capacity:6000 tons per month
- Various product: industrial aluminium profile , Aluminium profile for windows and doors,aluminum section for construction , aluminum extrusion profiles of furniture as per customer`s drawings and samples.
- Aluminum window and door style: aluminum aliding window and door,aluminum side hung windows and doors,aluminium shutter,aluminum thermal break window and door,aluminum curtain wall.
-
Chemical composition
Alloy
Si
Fe
Cu
Mn
Mg
Cr
Zn
Ti
Impurity
Al
6063
0.2-0.6
0.35
0.1
0.1
0.45-0.90
0.1
0.1
0.1
0.15
Rest
6061
0.4-0.8
0.70
0.15-0.40
0.15
0.8-1.2
0.04-0.35
0.25
0.15
0.15
Rest
6005
0.6-0.9
0.35
<0.1
<0.1
0.40-0.6
<0.1
<0.1
<0.1
<0.15
Rest
Mechanical property
Alloy
Condition
Tensile strength
Yield strength
Elongation
Vickers hardness
6061
T6
>265Mpa
>245Mpa
>8%
6063
T5
>160Mpa
>110Mpa
>8%
HV>58 HW>8
T6
>205Mpa
>180Mpa
>8%
Colored anodized profile
Grade
Thickness of film
Hole scaling quality of oxide layer
Average thickness
Local thickness
P. Cr acid-erosion weight less method
AA10
>10um
>8mm
<30 mg/d m2
AA15
>15um
>12um
Electrophoretic coating profiles
Grade
Anodic oxide film
Thickness of paint film
Thickness of complex film
Film hardness
Average thickness
Local thickness
A
>10um
>8um
>12um
>21um
>3um
B
>10um
>8um
>7um
>17um
>3um
Powder coating & wooden-grained profile
Coating thickness
Coating impress rigidity
Adhesive force of coating layer
40-120um
Indentation hardness>80
0 grade
Delivery date
a). Die/Mould:10 to 12 days after down payment & drawings confirmed.
b).Production: 15-20 days after sample confirmed & down payment for the second order ,and for the first order it need about 20-25days for one container.
c).Package:standard export packing,that is Epe foam to seperat the profiles and the outside to use the Kraft paper for each bundle ,or carton box or pallet or according to client request.
OEM are welcome,and inquiry of aluminium are welcome .
Looking forwarder to cooperation wih you .
Sales Depart. Marana
