Home > Metallurgy, Mineral & Energy > Steel & Products > Steel H Beam > Q235B Hot Rolled H Beam/channel
US$ 420 - 500
MOQ: 10 Tons
Key Specifications
Get Latest Price
Place of Origin:
Tianjin, China
Grade:
Other, Q235B and Q345B
Technique:
Hot Rolled
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Q235 Steel Angle in Stock With Lowest PriceUS$ 450 - 500MOQ: 2 Tons -
Q235 Unequal Black Steel Angle With HolesUS$ 500 - 600MOQ: 10 Tons
-
Steel Angle IronUS$ 450 - 580MOQ: 10 Tons
-
Standard Size of Mild Steel AngleUS$ 450 - 580MOQ: 10 Tons
-
Galvanized Mild Steel Angle 50x50x5US$ 450 - 580MOQ: 10 Tons
Place of Origin
Tianjin, China
Grade
Other, Q235B and Q345B
Technique
Hot Rolled
Thickness
6-18mm
Application
construction
Length
6-12m
Standard
BS
Flange Width
100-300mm
Flange Thickness
8-28mm
Web Width
100-900mm
Web Thickness
6-16mm
Brand Name
TYT
Model Number
H beam
Product Description
Prime quality hot rolled H beam/channel
1.Materials: S235JR, S235JO, S355JRH,SS400, Q235B,Q345B
2.Standard: ASTM,AISI, BS, DIN, GB, JIS
3.Type:hot rolled or welded
4.Surface: Black bared ,galvanized,painted
5.MOQ: 10 tons
6.Payment:TT deposit +BL copy or LC st sight
7.Angle normal sizes as below , special sizes if needed pls contact us for more details .
| Grade | Chemical Composition & Mechanical Properties | |||
| GB-Q235B Equal to JIS-SS400 or ASTM-A36 | Chemical Composition | |||
| C:0.12-0.20,Si:≤0.30,Mn:0.30-0.67,S:≤0.045,P: ≤0.04 | ||||
| Mechanical Properties | ||||
| Y.S.≥235 Mpa, T.S.:375-500 Mpa,El≥26% | ||||
| GB-Q345B Equal to JIS-SS490 or ASTM-A572 | Chemical Composition | |||
| C:≤0.20,Si:≤0.55,Mn:1.0-1.6,S:≤0.04,P: ≤0.04 | ||||
| Mechanical Properties | ||||
| Y.S.≥345 Mpa, T.S.:470-630 Mpa,El ≥22% | ||||
| SIZE (MM) | WEIGHT (KG/M) | SIZE (MM) | WEIGHT (KG/M) | |
| 100*100*6*8 | 17.2 | 388*402*15*15 | 141 | |
| 125*125*6.5*9 | 23.8 | 390*300*10*16 | 107 | |
| 148*100*6*9 | 21.4 | 394*398*11*18 | 147 | |
| 150*150*7*10 | 31.9 | 394*405*18*18 | 169 | |
| 150*75*5*7 | 14.3 | 396*199*7*11 | 56.7 | |
| 175*175*7.5*11 | 40.3 | 400*150*8*13 | 55.8 | |
| 175*90*5*8 | 18.2 | 400*200*8*13 | 66 | |
| 194*150*6*9 | 31.2 | 400*400*13*21 | 172 | |
| 198*99*4.5*7 | 18.5 | 400*408*21*21 | 197 | |
| 200*100*5.5*8 | 21.7 | 414*405*18*28 | 233 | |
| 200*200*8*12 | 50.5 | 428*407*20*35 | 284 | |
| 200*204*12*12 | 56.7 | 440*300*11*18 | 124 | |
| 244*175*7*11 | 44.1 | 446*199*8*12 | 66.7 | |
| 248*124*5*8 | 25.8 | 450*150*9*14 | 65.5 | |
| 250*125*6*9 | 29.7 | 450*200*9*14 | 76.5 | |
| 250*250*9*14 | 72.4 | 482*300*11*15 | 115 | |
| 250*255*14*14 | 82.2 | 488*300*11*18 | 129 | |
| 294*200*8*12 | 57.3 | 496*199*9*14 | 79.5 | |
| 294*302*12*12 | 85 | 500*200*10*16 | 89.6 | |
| 298*149*5.5*8 | 32.6 | 506*201*11*19 | 103 | |
| 300*150*6.5*9 | 37.3 | 582*300*12*17 | 137 | |
| 300*300*10*15 | 94.5 | 588*300*12*20 | 151 | |
| 300*305*15*15 | 106 | 594*302*14*23 | 175 | |
| 338*351*13*13 | 106 | 596*199*10*15 | 95.1 | |
| 340*250*9*14 | 79.7 | 600*200*11*17 | 106 | |
| 344*348*10*16 | 115 | 606*201*12*20 | 120 | |
| 344*354*16*16 | 131 | 692*300*13*20 | 166 | |
| 346*174*6*9 | 41.8 | 700*300*13*24 | 185 | |
| 350*175*7*11 | 50 | 792*300*14*22 | 191 | |
| 350*350*12*19 | 137 | 800*300*14*26 | 210 | |
| 350*357*19*19 | 156 | 900*300*16*28 | 243 | |
