UL 1242 ANSI C80.6 Intermediate Metal Conduit (IMC)
Size:1/2"-4"
Material: steel
Intermediate Metal Conduit (IMC) is manufactured in accordance with:
>American National Standards for Steel. (ANSI C80.6)
>Underwriters Laboratories Standard for Electrical Metallic Tubing.(UL 1242).
Intermediate Metal Conduit (IMC) is threaded on both ends, one end is with a steel coupling,and the other end is with a plastic cap to prot IMC conduit-UL1242 C80.6 ect the thread.
Surface: Hot-dip galvanized or Pre- galvanized
Finished:Hot-dip galvanized
| IMC (Intermediate Metal Conduit) Dimensions and Weights | ||||||||
| Nominal Diamension | Outside Diameter | Wall Thickness | Length | Weight | ||||
| Size | Size | |||||||
| Inch | mm | Inch | mm | Inch | mm | FT | mm | KG/PC |
| 1/2" | 16 | 0.802 | 20.7 | 0.077 | 1.98 | 10 | 3050 | 2.78 |
| 3/4" | 21 | 1.012 | 26.1 | 0.081 | 2.1 | 3.79 | ||
| 1" | 27 | 1.271 | 32.8 | 0.091 | 2.35 | 5.38 | ||
| 1-1/4" | 35 | 1.612 | 41.6 | 0.094 | 2.42 | 7.13 | ||
| 1-1/2" | 41 | 1.853 | 47.8 | 0.098 | 2.54 | 8.65 | ||
| 2" | 53 | 2.322 | 59.9 | 0.103 | 2.67 | 11.49 | ||
| 2-1/2" | 63 | 2.814 | 72.6 | 0.157 | 4.06 | 18.1 | ||
| 3" | 78 | 3.422 | 88.3 | 0.157 | 4.06 | 22.3 | ||
| 3-1/2" | 91 | 3.911 | 100.9 | 0.157 | 4.06 | 25.6 | ||
| 4" | 103 | 4.391 | 113.3 | 0.157 | 4.06 | 29.1 | ||
Dimensions for Thinwall Thickness
Finish:Pre-galvanized
| Model | Trade Size designator | Nominal outside Dia. | Nominal Wall Thickness | Length | ||||
| U.S. | Metric | in. | mm | in. | mm | mm | mm | |
| IMC-50 | 1/2" | 16 | 0.815 | 20.7 | 0.07 | 1.79 | 3000 | 3050 |
| IMC-75 | 3/4" | 21 | 1.029 | 26.1 | 0.075 | 1.9 | 3000 | 3050 |
| IMC-100 | 1" | 27 | 1.29 | 32.77 | 0.085 | 2.15 | 3000 | 3050 |
| IMC-125 | 1-1/4" | 35 | 1.638 | 41.59 | 0.085 | 2.16 | 3000 | 3050 |
| IMC-150 | 1-1/2" | 41 | 1.883 | 47.82 | 0.09 | 2.29 | 3000 | 3050 |
| IMC-200 | 2" | 53 | 2.36 | 59.93 | 0.095 | 2.41 | 3000 | 3050 |
| Model | Trade Size designator | Nominal outside Dia. | Nominal Wall Thickness | Length | ||||
| U.S. | Metric | in. | mm | mm | mm | |||
| IMC-50T | 1/2" | 16 | 0.815 | 20.7 | 1.6 | 3000 | ||
| IMC-75T | 3/4" | 21 | 1.029 | 26.1 | 1.7 | 3000 | ||
| IMC-100T | 1" | 27 | 1.29 | 32.77 | 2 | 3000 | ||
| IMC-125T | 1-1/4" | 35 | 1.638 | 41.59 | 2 | 3000 | ||
| IMC-150T | 1-1/2" | 41 | 1.883 | 47.82 | 2.1 | 3000 | ||
| IMC-200T | 2" | 53 | 2.36 | 59.93 | 2.2 | 3000 | ||
UL 797 EMT BS4568 CONDUIT BS 31 CONDUIT UL 6 RSC
Dongpengboda (Tianjin) Industrial Co.,Ltd.We have a total of 17 steel production lines to produce UL 797 EMT/BS4568 CONDUIT/BS31 CONDUIT/UL 1242 IMC & UL 6 RSC,Pls contact with me to get our quotation list.
