Specifications
ANSI C80.1 steel conduit pipe1.Standard:UL 797 ANSI C 80.3
2.Length:3.05m
3.Material:Q195 Q235 Q345
4.OD:1/2"-4"
ANSI C80.1 steel conduit pipe UL797 list
Details:
For pre-gal emt conduit,made of high pre-galvanized steel sheet.For hot dip galvanized emt conduit , made of high quality black pipe, after degreasing, washing in water, pickling, rinsing, drying and hot dip galvanized.Free from black spots and bubbles, strong corrosion resistance and long life.Widly used in all severe environment and provide good protection for the electrical raceway system.
1) Your size is always available.
2)Common length is 3.05m
3)There are 1/2 ",3/4",1",1-1/4",1-1/2", 2" , 2-1/2",3" and 4" for your reference
4)No thread both sides of the EMT pipe
5)Thinner EMTconduit is available
6)Timely delivery, good service, affordable price
Following is the size for your reference
Norminal Trade Size |
Outside Diameter |
Wall Thickness |
Length |
|||
U.S. |
Metric |
inch |
mm |
inch |
mm |
mm |
1/2" |
16 |
0.706 |
17.93 |
0.042 |
1.07 |
3050 |
3/4" |
21 |
0.922 |
23.42 |
0.049 |
1.25 |
3050 |
1" |
27 |
1.163 |
29.54 |
0.057 |
1.45 |
3050 |
1-1/4" |
35 |
1.150 |
38.35 |
0.065 |
1.65 |
3050 |
1-1/2" |
41 |
1.740 |
44.20 |
0.065 |
1.65 |
3050 |
| 2" | 53 | 2.197 | 55.80 | 0.065 | 1.65 | 3050 |
2-1/2" |
63 |
2.875 |
73.03 |
0.072 |
1.83 |
3050 |
3" |
78 |
3.500 |
88.90 |
0.072 |
1.83 |
3050 |
3-1/2" |
91 |
4.000 |
101.60 |
0.083 |
2.11 |
3050 |
4" |
103 |
4.500 |
114.30 |
0.083 |
2.11 |
3050 |
Thinwall Thickness
| Norminal Trade Size | Outside Diameter | Wall Thickness | Length | |||
U.S. |
Metric |
inch |
mm |
inch |
mm |
mm |
1/2" |
16 |
0.706 |
17.93 |
0.027 |
0.70 |
3050 |
3/4" |
21 |
0.922 |
23.42 |
0.031 |
0.80 |
3050 |
1" |
27 |
1.163 |
29.54 |
0.035 |
0.90 |
3050 |
1-1/4" |
35 |
1.150 |
38.35 |
0.047 |
1.20 |
3050 |
1-1/2" |
41 |
1.740 |
44.20 |
0.047 |
1.20 |
3050 |
2" |
53 |
2.197 |
55.80 |
0.049 |
1.25 |
3050 |
Applicable Tolerances:
Length: 10Ft (3.05m) ± ¼” (±6.35mm).
Outside Diameter: ½”-2” ±0.005” (±0.13mm); 2½” ±0.010” (±0.25mm); 3” ±0.015” (±0.38mm); 3½”-4” ±0.020” (±0.51mm)
