Specifications
1.Material:Q195-Q3452.Standard:JIS,DIN,BE,EN
3.Surface:Oiled,Galvanized,Painted
4.Application:Furniture,Handrail,Fencing
Oval pipe, flat oval pipe and elliptic pipe
The specialty of the oval pipe is the form itself. We offer two different types of oval pipe forms.
One is the elliptic pipe and the other the flat oval type.
Steel Grade: Q235, Q345, S235JR, S275JR, SS4007, Stainless
Flat oval pipes
Oval pipes are mainly produced with a diameter of 1,0 - 3,0 mm. Different wall thickness, materials and surfaces (e.g. IIIc, K240, K400, K600) as well as lengths can be produced on inquiry.
flat oval pipes
a | b | d | length in mm | material |
30,0 | 15,0 | 1,5 | 6.000 | 1.4301 |
30,0 | 17,0 | 1,5 | 6.000 | 1.4301 |
35,0 | 15,0 | 1,5 | 6.000 | 1.4301 |
40,0 | 20,0 | 1,5 | 6.000 | 1.4301 |
48,0 | 20,0 | 1,5 | 6.000 | 1.4301 |
56,5 | 29,8 | 1,5 | 6.000 | 1.4301 |
60,0 | 20,0 | 1,5 | 6.000 | 1.4301 |
60,0 | 32,0 | 2,0 | 6.000 | 1.4301 |
Elliptic pipe
Elliptic pipes can generally be produced from 1,0 - 3,0 mm. Different wall thickness, material and surfaces (e.g. IIIc, K240, K400, K600) as well as length can be produced in inquiry.
Oval pipe elliptic
a | b | d | length in mm | material |
26,3 | 16,2 | 1,5 | 6.000 | 1.4301 |
36,0 | 14,0 | 1,5 | 6.000 | 1.4301 |
40,0 | 28,5 | 1,5 | 6.000 | 1.4301 |
55,0 | 18,0 | 1,5 | 6.000 | 1.4301 |
