Home > Products > BS4568-BS31 EMT Conduit > BS4568 Electrical gi Conduit Pipe Specification Made in China Market
BS4568 Electrical gi Conduit Pipe Specification Made in China Market
US$ 0.6 - 20.59
/ Ton
5 Tons(Min. Order)
- Tianjin/Xingang
- T/T L/C D/P D/A Money Gram Credit Card
You May Like
Product Details
| Thickness | 1.2, 1.65 | Section Shape | Round | |
| Outer Diameter | 16 - 114 mm | Place of Origin | Tianjin, China | |
| Secondary Or Not | Non-secondary | Application | Structure Pipe | |
| Technique | ERW | Certification | BSI | |
| Surface Treatment | Galvanized | Special Pipe | EMT Pipe | |
| Alloy Or Not | Non-alloy |
Product Description
China exporter factory mill BS4568 electrical gi conduit pipe specification
Standard
BS4568
Following is the size for your reference
Material: galvanized steel coil
Finish:hot dipped galvanized (class 4)or pre galvanized(class 3)
End:threaded both ends,one end is coupling and other end is plastic cap
| BS4568:1970 Class 4 and Class 3 Conduit Specification Sheet | |||||||
| SIZE | Outside Diameter | Wall Thickness | Length | Length of Thread | |||
| (mm) | A | B | (mm) | ||||
| Min | Max | (mm) | (mm) | (m) | Min | Max | |
| 16mm | 15.7 | 16 | 1.4±0.15 | 1.2 | 3.75 | 11.5 | 13.5 |
| 20mm | 19.7 | 20 | 1.6±0.15 | 1.2 | 3.75 | 13 | 15 |
| 25mm | 24.6 | 25 | 1.6±0.15 | 1.2 | 3.75 | 16 | 18 |
| 32mm | 31.6 | 32 | 1.6±0.15 | 1.2 | 3.75 | 18 | 20 |
| 40mm | 39.5 | 40 | 1.6±0.15 | 3.75 | 19 | 22 | |
| 50mm | 49.5 | 50 | 1.6±0.15 | 3.75 | 19 | 22 | |
| 60mm | 59.5 | 60.3 | 2.0±0.15 | 3.75 | |||
| 75.5mm | 75 | 75.5 | 2.0±0.15 | 3.75 | |||
| 88.5mm | 88 | 88.5 | 2.0±0.15 | 3.75 | |||
| 114mm | 113.5 | 114 | 2.0±0.15 | 3.75 | |||
