construction aluminum foil woven fabric cloth thermal insulation materials with multiple layers
| Physical Property | Test Value | Test Method |
| Appearance | silver/customized | |
| Composition | Alu foil/PE/Woven fabric/PE | |
| Width(mm) | 80/100/120/125/150/160 | |
| Length(m) | 50-2500 | |
| Basic weight | 125g/m2 | Scale |
| Water vapor penetration | 2.0ng/NS | ASTM E96-A |
| Tensile strength(MD) | 200N/25mm | GB/T453 |
| Tensile strength(TD) | 250N/25mm | GB/T453 |
| Bursting srength | 590N | Q/320281 NPB01 |
| Reflectivity | 91%-92% | |
| Treatment | FR/UV/VCI/perforated avaliable | |
| Temperature | 4 hours no decladding -30℃/90℃ | ASTM C1236 |
Our aluminum foil PE fabric insulation are mainly used under roof decking, unde attic rafters, over existing attic insulation, in floors, walls and crawl spaces,and in industrial and commercial buildings to block radiant heat coming into house through the roof during the summer and retain indoor heat generated during the winter. Also used as a moisture vapor barrier in air conditioning ductworks and color rooms. It is used as packing material. for big machine to prevent moisture and radiant heat to contact machine.
Product Benefits:
1.Eco-friendly , environment friendly and radiant barriers.
2.Aluminum foil woven fabric as a radiant barrier stops up to 97% of radiant heat transfer which improves the performance of the insulating material.
3.PE woven fabric provides high tensile strength and durability.
4.Aluminum foil woven fabric provides an efficient,space saving,and healthy method of temperature control and energy savings.
Remarks:
1.Above data are typical results and not the guaranteed performance.
2.Tolerance: Weight and Thickness : ±10% ; Width: ±2mm ; Length: ±0.5%
3.The products should be stored at room temperature away from wet and heat source.
4.Please do trial-application and make sure the product can serve the specific application before actually put it to use.
