Product Description
Laminated glass is a type of safety glass that holds together when shattered. In the event of breaking, it is held in place by an interlayer or film, typically of polyvinyl butyral (PVB) or ethylene-vinyl acetate (EVA) or SGP film, between its two or more layers of glass.
Glass thickness: 3mm,5mm,6mm,8mm,10mm,12mm,15mm,19mm
Pvb thickness: 0.38mm,0.76mm,1.14mm,1.52mm,1.90mm,2.28mm
FEATURES
1) Extremely high safety: The PVB interlayer withstands penetration from impact.
2) Energy-saving building materials: PVB interlayer impedes the transmission of solar heat and reduces cooling loads.
3) Create aesthetic sense to building: Laminated glass with a tinted interlayer will beautify the buildings and harmonize their appearances with surrounding views which meet the demand of architects.
4) Sound control: PVB interlayer is an effective absorber of sound.
5) Ultraviolet screening: The interlayer filters out ultraviolet rays and prevents the furniture and curtains fro fading effect.
Processing technique
Two layers of glass "sandwiched" together with a PVB interlayer, laminated glass is the one glass that reconciles the aesthetic benefits of glass with a genuine concern for safety; offering superior protection against glass breakage, as well as harmful solar rays and hazardous noise levels.
Due to the adhesive properties of the PVB, Rider takes careful precautions to prevent unwanted particles from attaching to the PVB during the adhesion process.
Benefits
- Holds together when shattered. The PVB interlayer keeps the glass bonded, even when broken, resulting in a characteristic spider web cracking pattern across the glass.
- Cyclone resistant
- Superior UV blockage
- Excellent sound damping properties
- Low visible distortion
Laminated Glass Performance Levels according to Thickness
Glass Characteristic | Thickness (mm) | UV Transmittance (%) | LT (%) |
3+0.38+3mm Clear | 6.38mm | 5 | 89 |
6+0.38+6mm Clear | 12.38mm | 3 | 86 |
6+0.38+6mm Reflective | 12.38mm | 0.5 | 22 |
Laminated Glass Assembly According to Safety Requirement
REQUIREMENT | BENEFIT | GLASS ASSEMBLY |
Solar control | Energy saving | 2ply+1PVB interlayer |
UV elimination | ||
Sound control | Noise reduction | 2ply+1PVB interlayer |
Safety | Lowest injury risk | 2ply+2PVB interlayers |
Anti-bandit protection | 2ply+4-6PVB interlayers | |
Security | Forced entry protection | 3ply+4PVB interlayers |
Bullet proof | Decide case by case, at least | |
Blast resistant | 4ply+multi PVB interlayers |
Terms | Condition |
Product | 6.38mm Three Layers Blue Green Laminated Glass |
Thickness | 6.38mm, 8.38mm 10.38mm, 12.38mm, 6.76mm, 8.76mm, 10.76mm, 12.76mm |
MOQ | 1 FCL CONTAINER |
Payment Terms | 30% T/T in advance, and balance before shipment. |
Packing | Wooden crates worthy for ocean and land carriage. |
Glass Type | Tempered glass / Toughened glass |
|
Color | Clear / Ultra-clear / Green / Grey / Bronze / Blue etc. |
|
Maximum Size | 2440*6500mm |
|
Minimum Size | 200*300mm | |
Thickness | Tempered:4-19mm half tempered :4-12mm |
|
Glass Type | Insulated glass |
|
Maximum Size | 2500*5000mm |
|
Minimum Size | 200*300mm |
|
Thickness | 3-19mm |
|
Spacer Thickness | 6mm, 9mm, 12mm, 15mm, 16mm, 20mm |
|
Regular Size | 5+9A+5 5+9A+5 low-e 5+9A+5 coated |
|
Glass Type | Laminated glass |
|
Maximum Size | 2500*7800mm |
|
Thickness | 3-19mm |
|
Total Thickness | 6.38-80mm |
|
PVB | 0.38-2.28mm (0.38mm, 0.76mm, 1.14mm, 1.52mm ) |
|
| Arch height< 50mm for curved laminated glass |
|
Regular Size | 5+0.38pvb+5 tempered or not 5+0.76pvb+5 |
|
Glass Type | Low-E glass |
|
Low-E Types | On line Low-E Glass |
|
Maximum Size | 2440*3660mm |
|
Minimum Size | 300*700mm |
|
Thickness | 3-19mm |
|
Popular Size | 2134*3050mm 2440*3050mm 2134*3300mm 2440*3300mm 2134*3660mm 2440*3660mm |
|
Glass Type | Online reflective coated glass |
|
Color | Silvery grey, grey, blue grey, blue, lake blue, grayish green, |
|
Green, bluish green, golden, tawny, champagne, etc. |
| |
Maximum Size | 2440*7200mm |
|
Minimum Size | 350*600mm |
|
Thickness | 3, 4, 5, 6, 8, 10, 12, 15mm |
|
Packing | Safe Plywood cases and interlayer paper between glass |
|
Lead Time | On time delivery |
|
Whether u request one container or a bulk shipment,we also attaches great importance to the details in every order,do a good job in each shipment. |
| |
Laminated Glass advantage
- We manufacture a wide range of glass to meet your different demands: Float glass, Tinted glass, Stained glass, Laminated glass, Mirror glass, Aluminum mirror, Silver mirror, Reflective glass, Online coated glass, Patterned glass, Figured glass, Wired glass, Colored glass, Tempered glass, Toughened glass, Safety glass, Shower doors glass, Emulsificated glass, Acid-etched glass, Obscure glass, Sandblasted glass, Solar glass, Ultra clear low iron glass, Low-E glass, Obscure glass, Glass block, Glass brick, Picture frame in different colors and sizes.
- 23 years' manufacturing experience.
- Six production lines to make sure of on time delivery, products will be shipped out within 15 days after deposit or L/C.
- Rider Glass ensures that you will receive the exact high quality glass you want at the most competitive prices.
- All the products are manufactured according to AS/NZS 2208 certificate, to make sure of perfect quality.
- Dockside warehousing in 3 of China’s top 5 container ports ensures convenient loading and rapid delivery of Rider Glass.
- Wide assortment of colors and customization options make it even easier to make all your glass purchasing decisions from one supplier.
- We give each customer personalized, professional, and dedicated service.
- From order to delivery to after sales service, our devoted team of experienced sales professionals is always available to give prompt replies and service.
- No matter the requirement, at Rider Glass we are always at your service.
FAQ
Q: Can you do the production as customized?
A: Yes, we have a professional technique team, we could produce the glass depends on your requirements.
Q. What the your glass package ? Are they safe ?
Answer :Seaworthy strong plywood crates with paper interleave . The crates will be very strong and every loading worker has 23 years packed, loading and fixation crates with container experience. And we send the loading pictures for you after we loading .
Q. What is your payment term ?
Answer : Our payment term is T/T 30% in advance ,70% after get the copy of B/L .
If your glass quantity is less, we want to TT 100% . You can payment By T/T, L/C at sight.
Q. Can you supply a free samples ?
Answer: yes, if you want us to provide big size sample according to your requirements, you should pay the cost of production.
