PP Compression Fittings straight coupling
- NIngbo or Shanghai
- T/T D/P D/A
You May Like
-
PE Compression Fittings pipe branch tee fitting
-
China supplier all size PP Compression for PE Fitting Reducing Tee
-
PP Compression Fittings Female Elbow
-
Agriculture irrigation system PP compression fitting for PE pipe
-
pn16 high pressure Male Threaded Coupler
-
PP Compression reducing coupling for pe pipe
Product Details
Material | Plastic | Technics | Other, Injection Molding | |
Type | Coupling | Place of Origin | Zhejiang, China | |
Model Number | 7201 | Brand Name | Evergreen or OEM | |
Connection | Other, socket | Shape | Equal | |
Head Code | Square |
Product Description
Products Name: PP Compression Fittings straight coupling
Products Details:
1.Product Name: | PP Compression Fitting |
2.Main Material: | PP (Polypropylene) |
3.Products Color: | blue, grey or customized. |
4.Working Pressure: | 10-16Bar |
5.Product Size: | 20,25,32,40,50,63,75,90,110mm |
6. Quality control: | 100% pre-shipment inspection |
Material List:
Part | Material | Color |
Body | Polypropylene block copolymer(PP-B) of exceptional mechanical properties even at high temperature. | black |
Nut | Polyprolene with dye master of high stability to UV rays and solidity to heat(8 grade according to standard DIN 54004) | blue,gray or customized |
Clinching ring | Polyacetal resin(POM)with high mechanical resistance white and hardness | white |
Blocking bush | Polypropylene | black |
O Ring gasket | Special elastomeric acrylonitrile rubber(NBR) for alimentary use | black |
Reinforcing ring | AISI 430(UNI X8Cr17,W.nr 14828)Stainless steel for female threads for 1/2”to 4” | silver |
Features & Application:
1. High corrosion resistance, long service life
2. PP has excellent chemical stability, good flexibility
3. Light weight, transport, easy to install and transport, lower maintenance costs
4. Nontoxic, no Leakage,higher flow capacity;
5. Recycled and Environment-friendly
6. Applied to agricultural irrigation, construction site, drainage and pump.etc.
Product Image:
Related Hot sale Series:
Working Picture:
Workshop Show:
Packaging:
1. Export Standard Packing for PP Compression Fittings straight coupling
2. As per customer's request
Shipping:
Sea shipment
Air shipment
Courier shipment
Service Advantage:
1. 10 years manufacturing and exporting experience in agriculture field.
2. Professional technical support and solution by Chief Engineer.
3. Strict quality control system & team, high reputation in the market.
4. Quick, efficient and professional response within 24 hours, 14 hours online services.
5. Multilingual communication services (English, Spanish, French, Portuguese, Japanese etc.)
6. Full range of irrigation products for choice.
7. Accept sample order before Mass Order.
8. OEM/ODM services.
