UV Resistant Transparent Solid Corrugated Polycarbonate Sheets (Valuview Clear series)
- 1000 Square Meter / Square Meters per Month
- Kaohsiung
- T/T
Product Details
Place of Origin: | Taiwan | Brand Name: | VULCAN Plasitcs Polycarbonate Sheet | Model Number: | Polycarbonate Valuview CLEAR |
Product Description
VULCAN PLASTICS
POLYCARBONATE VALUVIEW CLEAR SHEET MATERIAL
VULCAN Valuview Series is targeted towards projects seeking optimal price versus value. It offers highest the clarity of all among VULCAN Polycarbonate materials.
We use only 100% Virgin UV Included Bayer, Sabic, Mitsubishi material to ensure stable quality and lifespan of the product.
Production Method
- Co-Extrusion ensures evenly spread, evenly thick base material and UV coating. (A chain is only as strong as it’s weakest link.)
Base Material
- 100% Virgin UV included raw material ensures that your sheets can withstand harmful UV rays for at least one year.
UV400 Coating
- Co-extruded with the Base Material, our Optical Grade UV400 resin from Sumitomo Dow Chemicals Co., LTD (Now Sumitomo Styron), blocks harmful UV rays from 280~400nm. With UV400 coating, VULCAN Polycarbonate sheets are able to last 10 years or more.
Properties:
- Average heat reflective properties.
- Optimal price versus value rate.
Light Transmission Rate:
- For projects seeking optimal price and value and which requires direct light projection.
- Valuview Clear: 88%
VULCAN Polycarbonate Sheets comes in 4 different Corrugated Profiles - ROMA, TRIMDEK, GRECA, MINI
and 2 different Solid Profiles - SOLID FLAT and SOLID EMBOSSED/TEXTURED.
Material Grade
| Profile | Wave Span |
Wave Height | Width | Thickness | Length | |||
Min. | Max. | Min. | Max. | 20' | 40' | ||||
Valuview | ROMA | 76mm | 18mm | 9 Corrugations | 14.5 Corrugations | 0.6mm | 2.0mm | Max. | Max. |
670mm | 1060mm | 5800mm | 11600mm | ||||||
TRIMDEK | 190mm | 27mm | 5 Corrugations | 0.6mm | 2.0mm | Max. | Max. | ||
820mm | 5800mm | 11600mm | |||||||
GRECA | 76mm | 18mm | 12 Corrugations | 14~16 Corrugations | 0.6mm | 2.0mm | Max. | Max. | |
880mm | 1020~1170mm | 5800mm | 11600mm | ||||||
MINI | 32mm | 9mm | 31 Corrugations | 36 Corrugations | 1.0mm | 1.2mm | Max. | Max. | |
1000mm | 1180mm | 5800mm | 11600mm | ||||||
Solid Flat HITACHI ZOSEN) | - | - | 1200mm | 2100mm | 2.0mm | 15mm | Max. | Max. | |
5800mm | 11600mm | ||||||||
Solid Flat (Breyer) | - | - | 1200mm | 1950mm | 2.0mm | 12mm | Max. | Max. | |
5800mm | 11600mm | ||||||||
Embossed Solid Flat | - | - | 600mm | 1900mm | 1.6mm | 6mm | Max. | Max. | |
5800mm | 11600mm |
Through extensive testing, we have seen what the sun and excessive heat does to a poor product. Vulcan uses only first class, non-recycled material to ensure the lifespan of all our products, which in turn ensures the longlivity of your merchandise.
We are also the first Polycarbonate manufacturer in Asia to incorporate Class 5000 clean rooms for our extrusion lines. (the maximum number of particles per cubic foot of air of diameter greater or equal to 0.5 µm is 5000).
VULCAN Polycarbonate Sheets can be made to order and cut to length as per customer request. Any specification of either profile within their respetive production range on the Profile Table above can be produced.
Minimum Order Quantity is 10 tons per profile.
All sheets are co-extruded with SD Polyca Optical Grade UV400 coating and are warranted for 10yrs under normal circumstances*.
*Warranty details are listed on our online Installation Manual .tw/download/VP%20Corrugated%20Sheet%20Installation%20Instructions.pdf, failure to comply shall void warranty.
VULCAN PLASTICS was established in 2007 with the goal of exporting Polycarbonate Sheets of the highest level. With steady progress, we obtained ISO 9001 Certification in the year 2008.
Starting from 1991, we have established a strong foothold in the Polycarbonate Sheet Manufacturing Industry in Taiwan. Following market trends closely and constantly in pursuit of quality and perfection, we continue to develop high-class, multi-functional Polycarbonate Sheets to satisfy customer expectations.
For More information, visit our
Website: .tw
E-Catalogue: .tw/download/VULCAN%20Polycarbonate%20Sheets%20Catalogue.PDF
Youtube Channel: /user/VULCANPLASTICSTW for a brief tour of our factory.
We will be more than happy to assist you in choosing the right VULCAN Polycarbonate sheet for your application.
