Supply Steel Angel, Angle Bar

US$ 380 - 850 MOQ: 10 Metric Tons

Key Specifications

Standard:

AISI, ASTM, BS, DIN, GB, JIS

Dimensions:

20*20*3mm-200*200*24mm

Grade:

Q195-Q420 Series

Tianjin Erf Metal Structure Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xingang port China

Delivery Detail:

Delivery time depends on order quantity.

Standard AISI, ASTM, BS, DIN, GB, JIS

Dimensions 20*20*3mm-200*200*24mm

Grade Q195-Q420 Series

Brand Name Erf

Model Number Q235/Q345/SS400/S235/S275

Type Other, equal and unequal, angel bar

Application Construction, building,steel fabrication

Product Description

JIS Standard Equal Angles

Standard Sectional Dimension (mm)	Weight (kg/m)	Standard Sectional Dimension (mm)	Weight (kg/m)
20203	0.885	80806	7.32
25253	1.12	80807	8.48
30303	1.36	80808	9.55
30304	1.78	90906	8.25
30305	2.16	90907	9.59
38383	1.72	90908	10.90
38384	2.26	90909	12.20
40403	1.83	909010	13.30
40404	2.41	1001006	9.22
40405	2.95	1001007	10.70
50503	2.33	1001008	12.10
50504	3.06	10010010	14.90
50505	3.77	1201208	14.70
50506	4.43	12012010	18.20
60605	4.55	12012012	21.50
60606	5.41	1301309	17.90
65655	5.00	13013010	19.70
65656	5.91	13013012	23.40
65658	7.66	15015010	22.90
70705	5.37	15015012	27.30
70706	6.38	15015015	33.60
70707	7.35	20020015	45.30
75755	5.76	20020020	59.70
75756	6.85	20020024	71.10
75757	7.94	25025025	93.70
75758	8.92	25025028	104.00
75759	9.96	25025035	128.00

JIS Standard Unequal Angles

Standard Sectional Dimension(mm)	Thickness (mm)	Weight (mm)	Standard Sectional Dimension (mm)	Thickness (mm)	Weight (kg/m)
75*50	5	4.81	150*75	10	17.0
75*50	6	5.67	150*75	12	20.1
100*75	7	9.32	150*75	15	24.8
100*75	8	10.6	150*90	9	16.4
100*75	10	13.0	150*90	10	18.2
100*75	12	15.4	150*90	12	21.6
125*75	7	10.7	150*90	15	26.6
125*75	8	12.2	150*100	9	17.1
125*75	10	15.0	150*100	12	22.4
125*75	12	17.8	150*100	15	27.7
150*75	7	12.1	200*100	10	23.0
150*75	9	15.3	200*100	12	27.3
