Specifications
welded variable cross-section steel H beam columnDirect Manufacturer
material:Q235,Q345
technique: weilding
ACCORDING TO STANDARD: JIS G3192 OR GB/T11263-2005 | |||
H beam Section (mm) |
Weight (kg/m) |
||
Height×Breadth |
Web thickness |
Flange thickness |
|
100×100 |
6 |
8 |
16.9 |
125×125 |
6.5 |
9 |
23.6 |
150×150 |
7 |
10 |
31.1 |
175×175 |
7.5 |
11 |
40.4 |
200×200 |
8 |
12 |
49.9 |
250×250 |
9 |
14 |
71.8 |
300×300 |
10 |
15 |
93.0 |
300×300 |
15 |
15 |
105.0 |
350×350 |
12 |
19 |
134.9 |
400×400 |
13 |
21 |
171.7 |
148×100 |
6 |
9 |
20.7 |
194×150 |
6 |
9 |
29.9 |
244×175 |
7 |
11 |
43.6 |
294×200 |
8 |
12 |
55.8 |
340×250 |
9 |
14 |
78.1 |
390×300 |
10 |
16 |
104.6 |
440×300 |
11 |
18 |
120.8 |
482×300 |
11 |
15 |
110.8 |
488×300 |
11 |
18 |
124.9 |
582×300 |
12 |
17 |
132.8 |
588×300 |
12 |
20 |
147.0 |
100×50 |
5 |
7 |
9.3 |
125×60 |
6 |
8 |
13.1 |
150×75 |
5 |
7 |
14.0 |
175×90 |
5 |
8 |
18.0 |
198×99 |
4.5 |
7 |
17.8 |
200×100 |
5.5 |
8 |
20.9 |
248×124 |
5 |
8 |
25.1 |
250×125 |
6 |
9 |
29.0 |
298×149 |
5.5 |
8 |
32.0 |
300×150 |
6.5 |
9 |
36.7 |
346×174 |
6 |
9 |
41.2 |
350×175 |
7 |
11 |
49.4 |
396×199 |
7 |
11 |
56.1 |
400×200 |
8 |
13 |
65.4 |
446×199 |
8 |
12 |
65.1 |
450×200 |
9 |
14 |
74.9 |
496×199 |
9 |
14 |
77.9 |
500×200 |
10 |
16 |
88.1 |
596×199 |
10 |
15 |
92.4 |
600×200 |
11 |
17 |
103.4 |
700×300 |
13 |
24 |
181.8 |
800×300 |
14 |
26 |
206.8 |
900×300 |
16 |
28 |
240.1 |
1. The Features and Advantages:
--- If bear the same press, then the H Beam can save 10%-15% material.
--- You can have more designs of the rooms if you use H Beam than concrete.
--- The H Beam is light than the concrete, so it is easy to carry and cut the cost.
--- The Building will be more stable, if it is built by H Beam, especially the places where earthquake usually happened.
--- The H Beam is environmentally friendly and reduce the Nuisance dusts.
--- The H Beam can save the real working time, because it is easy to carry and can be used in any weather.
2. Application:
---H Beams can be used in the industry and construction.
---H Beams also can be used in the large Bridge.
---The industries of trains, automobiles and tractors also will use the H Beam.
---Frame Structure in marine and mechanical area.
process :
We have two factories, one of which already has more than nine years of experience. And we have establish a new factory. Our company is mainly engaged in cold bending steel, cold bend profiled steel, CZU type steel; Galvanized steel, steel door frame; Hot dip galvanized steel structure; Sisheng metal manufacturing, rolled plate kaiping; Steel, strip steel, and other products.
Contact informtion;
ADD: Room 1103, Xinyu Building, Jingwen Road, Jinghai Town, Jinghai County, Tianjin, China.
Mopile number: +86- 13001366216
Skype: Camille Yan
