LED Lamp Outdoor Driver Sign Traffic Radar Speed Feedback
- 100 Piece / Pieces per Month
- Keelung Port
- T/T Credit Card PayPal
You May Like
-
SSR-T40AA 40A Three Phase AC To AC Power SSR Relay
-
SSR-S25DA 25 Amp DC To AC Single Phase SSR Solid State Relay
-
SSR-S25AA-H Shining 25A AC to AC UL High Power 240V Output Relay
-
SSR-S10AA UL/CE Approval Solid State Electrical Relay AC 10A SSR
-
SSR-S40DA-H DC to AC Type CE 40A Single Phase Solid State Relay
-
SSR-S10DA-H UL/cUL Approval Electric Relays Single Phase 10A SSR
Product Details
| Place of Origin | Taiwan | Brand Name | SHINING | |
| Model Number | 18SFL25M22R09S |
1pc/ GW:28.5kgs (62.7lbs)/ NW: 26.5kgs(58.3lbs) / carton
Product Description
LED Lamp Outdoor Driver Sign Traffic Radar Speed Feedback |
| Gerneral Product Information | |
| Item number: | 18SFL25M22R09S |
| Power Source: | 9.5-25 VDC |
| System Power: | 0.736W |
| Radar Frequency: | 24.120-24.130GHZ |
| Operating Temperature: | -10 ~ 80 °C |
| Dimensions [mm] (EXAMPLE:) | |||
| Item No. | Length (L) | Width (W) | Height (H) |
| 18SFL25M22R09S | 715.0 mm | 640.0 mm | 227.5 mm |
Product Features |
| • Whole system driven by high efficient switching power supply. The highest efficient can reach 92%, provide best power saving performance. • Bi-directional detect allowed. • Standard power saving device provide automatic day-light saving, low LED driving watts, etc. • Whole system locate inside the external display box, suitable for out door usage. • Good ventilation design of display box provide excellent low temperature environments. • Weather resistance 5.5mm thickness PC plate window provide good protection for display board. • 1.5mm thickness SPCC for display box,provide rigid structure. Stainless hinge shaft provide long life for display box. |
1. Model Number: 18SFL25M22R09S Version V1.0
2. Power Source: 9.5-25 VDC
3. System Power Consumption: Approximately 0.736W for System board + Radar module.
4. Radar Frequency: 24.120-24.130GHz
5. Operating Temperature: Standard (-10~80 °C)/ (14~176 °F ); Optional (-40~80 °C)/ (-40~176 °F )
6. Signal Pick Up Distance: 250+M (820Ft+)note 2; (Azimuth: 12°; Elevation: 24°@3db)
7. Max. Speed Detect and Display Detect: 223KM(138Miles)/hour, Display: 199 KM(138Miles)/hour
8. RS232 COM port: Yes, optional device for GPRS, WIFI, Wireless via COM port are all available.
9. Real Time Clock: Yes, +/- 3ppm,
10. SD Storage Device: Yes, supports up to 32GB
11. Device Configuration Standard: via COM; Option: IR Remote control
12. Violation Speed & High Speed Cut Off Setting: Standard via COM, Manual (by thumb wheel). Option: IR Remote control.
13. Warning Flash: Will be lighted on when a vehicle violated speed.
14. Camera: Option only, (under developed). Control board provide a high/low voltage for system to trigger the camera.
15. FCC: Yes for radar module
16. Traffic Counter Function: Yes (optional)
17. Dimension: 728mm(28.66”)Width, 1016mm(40”)Height, 227mm(8.9”)Thickness;
Packed with Corrugated Carton; 5 layers Strength 14kg: 750mm(29.53”)W; 660mm(26.98”)H; 140mm(5.51”)T
18. Weight: Approximately GW: 28.5kgs (62.7lbs); NW: 26.5kgs(58.3lbs), battery not included
19. Power consumption (all LED light on): Maximum under daylight, approximately 12W. Minimum at night, approximately 4.2W
20. LED Display: 22pcs 5mm supper flux LED per segment; 16 Segments total; viewing angle 30 ° , Luminous Intensity 9000mcd for display LED. 9pcs flash LED provide strobe effect.
21. Battery: AC/DC power available as option; will be provided under
requisition.
Packaging |
| 1pc/ GW:28.5kgs (62.7lbs)/ NW: 26.5kgs(58.3lbs) / carton |
