Home > Products > Fuse Holders > FS-033 Taiwan RT18-32 Terminal Fuse Blocks Without LED Light
FS-033 Taiwan RT18-32 Terminal Fuse Blocks Without LED Light
- 100000 Piece / Pieces per Month
- Keelung
- Credit Card
- FS-018B 600V 10 Amp 8 Way Midget Type Din Rail Glass Fuse Holder
- FS-032L3 With LED Indicator 600V 32A 2 Pole 10x38 Fuse Carrier
- FS-032L3 UL Approved 600V 32A 2 Pole 10x38 Porcelain Fuse Holder
- FS-033L2 Din Rail Type With Indicator 3 Pole 32A 380V AC DC Fuse Carrier
- FS-032L1 LED Indicator 110V 32A 2 Pole 10x38 Cylindrical Fuse Holder
- FS-033L1 UL Approved 110V DC AC 32A RT18-32 Cylinder Fuse Holder
Product Details
Place of Origin: | Taiwan | Brand Name: | Shining | Model Number: | FS-33 |
Type: | Fuse Holder |
Packaging Details
100pcs/N.W. :19.0kgs /carton
Product Description
Specifications
FS-033 Taiwan RT18-32 Terminal Fuse Blocks Without LED LightRating:600V,32A,3P
Size:72*52.5*56mm
Wire Size:AWG8-20/8.4mm2
U
FS-033 Taiwan RT18-32 Terminal Fuse Blocks Without LED Light
•Item number: FS-033
•Rating: 600V, 32A, 3P
•Size: 72.0x52.5x56.0mm (LxWxH)
•Wire Size: AWG 20-8/ 0.52-8.4mm
•Molded from UL94-V2 material with excellent flame- and shock-resistance
•Suitable for 10x38mm fuse
•Excellent for switchboard panel, control consoles, small motors, transformers, air conditioners, power distribution and similar applications.
•Without LED Indicator
•Packing: 5pcs/box, 100pcs/20box, N.W. :19.6kgs /carton
•Webpage: FS-03X Series Din Rail Mounted Fuse Holder
Item No. | FS-031 | FS-032 | FS-033 | |||||
Specifications/Dimensions | ||||||||
Length (L) | 72 mm | 72 mm | 72 mm | |||||
Width (W) | 17.5 mm | 35 mm | 52.5 mm | |||||
Height (H) | 56 mm | 56 mm | 56 mm | |||||
Poles | 1 | 2 | 3 | |||||
Rated Toque [in-lb] | 17 in-lb | 17 in-lb | 17 in-lb | |||||
Electrical Specifications | ||||||||
Rated Voltage | 600 V | 600 V | 600 V | |||||
Rated Current | 32 A | 32 A | 32 A | |||||
Wire Size (AWG) | #8-20 AWG | #8-20 AWG | #8-20 AWG | |||||
Wire Size [mm2] | 0.52~8.4 mm2 | 0.52~8.4 mm2 | 0.52~8.4 mm2 | |||||
Materials | ||||||||
Body Materials | PBT | PBT | PBT | |||||
Color | White | White | White | |||||
Flame Retarded Grade | UL 94V-0, V-2 | UL 94V-0, V-2 | UL 94V-0, V-2 | |||||
Temperature [oC] | 120oC | 120oC | 120oC | |||||
Accessories & Parts | ||||||||
Ava. Fuse Specifications | 10x38 mm fuse (13/32"x 1 1/2") | 10x38 mm fuse (13/32"x 1 1/2") | 10x38 mm fuse (13/32"x 1 1/2") | |||||
Indicators | N/A | N/A | N/A | |||||
DIN Rail Adapter | Embedded | Embedded | Embedded | |||||
Ava. DIN Rail | TA-001A, TA-001S (35mm DIN Rail) | TA-001A, TA-001S (35mm DIN Rail) | TA-001A, TA-001S (35mm DIN Rail) | |||||
Ava. End Clamp | TA-002, TA-002H TE-002 TF-ECL, TF-ECH | TA-002, TA-002H TE-002 TF-ECL, TF-ECH | TA-002, TA-002H TE-002 TF-ECL, TF-ECH | |||||
Approval | N/A | N/A | N/A |
