Product Details
Place of Origin: | Guangdong, China | Brand Name: | U-sure | Model Number: | U-PTZ |
Material: | Other, PVC, Raw PVC material,anti-UV agent and other chemical materials | Type: | Plain Roof Tiles |
Product Description
High durability anti-loading plastic pvc roof tile
Features:
1.Lasting Color :
It boasts extraordinary durability in natural environment . It is able to maintain its stable color even under long term exposure to such severe conditions as ultraviolet rediation , dampness , heat and coldness.
2.Excellent weatherability :
Ultra-weather proof surface to ensure the durability of products , the thickness of surface layer≥0.2mm .
3.Excellent corrosion resistance :
In the salt , alkali and following a 24-hour soaking in 60% acid , no chemical reaction and no fading . Very suitable for acid rain-prone areas ,corrosive workshop and coastal area use , the effect was particularly significant.
4.Good sound insulation :
The tests prove that : in suffering heavy rain , high winds the impact of outside noise , it has a good absorption of the noise effect , noise down 30bB than color steel tile.
5.Extraordinary heat preservation and heat insulation :
Heat insulation-3~5 centidegree lower than steel tile .
6.Insulativity :
It’s insulation products , will also be intact in an accident discharge .
7.Fire retardant :
Through the national fire authority of the deparment according to standards for testing , fire safety performance ≥ B grade.
8. Impact resistance and cold resistance , it's recommended to use for cold area :
Good impact resistant capacity , the test proves the falling of 1KG steel ball from 3 meters high can not make it crack , it also has good inpact resistant performance in cold environment.
9.Excellent thermal insulation :
Its thermal conductivity coefficient is 0.325w/mk , clay tile is about 1/310 , cement tile 1/5,0.5mm color steel tile 1/2000. Its heat insulation capacity is much improved comparing with two layer co-extrusion tile.
Specification:
Thickness | 0.8mm/1.0mm/1.3mm/1.5mm /2.0mm /2.5mm/3.0mm |
Width | 840mm/930mm/1120mm/1130mm |
Length | 5800mm,11800mm or customized according to requirement of customers |
Color | white , blue , pale yellow , green , gray , brick red |
Layer | 1 layer,2 layer,3 layer,4 layers |
Guarantee of quality | ASA (25 years) APVC (15 years) UPVC (10 years) |
Application:
High-grade plants , steel factories , warehouses , farm market , market access , sheds and other high-end roofing materials. Especially in corrosive chemical plants , smelters , ceramic plants , soy sauce factory , chemical plants , printing and dyeing plant , organic solvent factory , acid , alkali and other corrosive plant.
To facilitate the product installation,our company has developed the patented comprehensive anticorrosive mounting accessories as shown below.
Illustration : The above accessories can be applied to the profiles of ASA composite corrugated roofing tile , APVC anti-corrosive complex corrugated sheet , and PVC translucent corrugated sheet .
1.Roof structure with steel or wood purlin , purlin requirements for smooth , not deformed , and two parallel , span uniform.
2.The thickness 2.0mm of the tile panels , suggested purlin span≤700mm;
3.The thickness of 2.5mm and 3.0mm tile , suggested purlin span≤800mm;
4.Transverse joint must be complete and ride a wave , longitudinal lap length>200mm;
5.If using a self-tapping screw fixation must be a pre-drilled hole , aperture than the screw diameter 50% , or a screw and compression code with the use of screws ,locking shall not be too tight , otherwise cause stress , surface crack caused by local.
6.Fixed screw or hook tile number of calls per square tile plate not less than five sets;
7.Tile lap to consider the slope and perennial leading to wind effects , tile panels arranged sequentially and laying with local perennial leading wind instead , namely the tile plate lateral portions of the interface to be carried with the dominant wind direction.
Thickness | 0.8 mm | 1.0 mm | 1.5 mm | 2.0 mm | 2.5 mm | 3.0 mm |
proportion | 1.52 KG/m2 | 1.9 KG/m2 | 2.85 KG/m2 | 3.8 KG/m2 | 4.75 KG/m2 | 5.7 KG/m2 |
Length | 5800mm,11800mm or customized according to requirement of customers | |||||
Container Load Capacity | Thickness | Square meters / 20 FCL (21 Tons) | Square meters / 40 FCL (26 Tons) | |||
0.8 mm | 13800 m2 | 17100 m2 | ||||
1.0 mm | 11000 m2 | 13600 m2 | ||||
1.5 mm | 7300 m2 | 9100 m2 | ||||
2.0 mm | 5500 m2 | 6800 m2 | ||||
2.5 mm | 4400 m2 | 5400 m2 | ||||
3.0mm | 3600 m2 | 4500 m2 |
