Steel Constructure Container Frame

Name: Steel Constructure Container Frame
Brand: hsdmcl
SKU: 141838986
Availability: InStock

US$ 1,000 - 2,000 MOQ: 2 Units

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

hsdmcl

Model Number:

hsd A4

Laizhou Hongshengda Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name hsdmcl

Model Number hsd A4

Material Steel

Use House, Office, Shop

Specifications

Container frame use in container house with steel metal and EPS sandwich panels.

No.	NAME	ITEMS
1	Outside Wall panel	50mm thickness of EPS/ double color steel panel, 0.4mm thickness/8K foam
2	Top roof panel	50mm thickness of EPS/ double color steel panel, 0.4mm thickness/8K foam
3	Main Foundation Frame	14# slot steel
4	Main beam	2mm thickness70*50mm square tuble
5	Bottom secondary beam	2mm thickness60*60mm square tuble
6	Column	made by 4mm steel sheet
7	Top frame	16# slot steel
8	Wall panel channel	color steel plate
9	Corner covering	0.4mm color sheet steel
10	Basic floorboard	1220*2440 multi-plywood
11	Main enter Door	sandwich panels door 90*200cm
12	corner casing	standard container corner casing
13	electricity	lamp,electricity line,socket,etc
14	accessories	bolt, screw, seal glue, aluminum material
15	roof load	0.5KN/sqm(If the criteria were exceeded, it can also load by reinforcing the structure)
16	wind pressure load parameter	designing wind speed 210km/h (Chinese standard)
17	seismic fortification intensity	magnitudes 8
18	suitable temperature	suitable temperature scope.-50°C~+50°C
19	contruction tools
20	construction efficiency	4 experienced technicians can build 6-8 prefab houses with dimension of 20 feet
21	container trunk	container with 12 meters can load 8 houses with the dimension of 20 feet
