Specifications
1.life span of use about 50 years.2.easy shipping and quick installation.
3.save energy & environmental.
4.water proof.
steel carport canopy garage design
Product description
Steel stucture poultry shed building is a new type of building structure system . The main steel frame is formed by linking up H-section,Z-section and U-section steel components while roof and wall using a variety of panels.
Specifications:
Opinions | 1)We can supply all kinds of steel structures, steel building, metal building, modular house, steel frame for warehouse, workshop, garage etc, steel beams, other riveting and welding parts. |
2)We can also make and develop new parts according to customers' drawings and detailed dimensions. | |
Specifications | 1)Size: MOQ is 100m2, width X length X eave height, roof slope |
2)Type: Single slope, double slope, muti slope; Single span, double-span, Multi-span, single floor, double floors! | |
3)Base: Cement and steel foundation bolts | |
4)Column and beam: Material Q345(S355JR)or Q235(S235JR) steel, all bolts connection! Straight cross-section or Variable cross-section! | |
5)Bracing: X-type or V-type or other type bracing made from angle, round pipe, etc | |
6)C or z purlin: Size from C120~C320, Z100~Z200 | |
1)Roof and wall panel: Single colorfull corrugated steel sheet0.326~0.8mm thick,(1150mm wide), or sandwich panel with EPS, ROCK WOOL, PU etc insulation thickness around 50mm~100mm. | |
2)Accessories: Semi-transparent skylight belts, Ventilators, down pipe, Glavanized gutter, etc | |
3)Surface: Two lays of Anti-rust Painting! | |
10) Packing: Main steel frame without packing load in 40'OT, roof and wall panel load in 40'HQ! | |
Design Parameters | If you need we design for you, pls supply us the following parameter together with detail size: |
1)Live load on roof(KN/M2) | |
2)Wind speed(KM/H) | |
3)Snow load (KG/M2) | |
4)Earthquake load if have | |
5)Demands for doors and windows | |
6)Crane (if have) , Crane span, crane lift height, max lift capacity, max wheel pressure and min wheel pressure! |
Characteristics:
A. Stable structure: Light steel structure, safe and stable, can accord with the construction structure design standards.
B. Easy to reassemble: Can be used repeatedly. Only simple tools are needed during the installtion. 20-30m2 can be finished each day by one worker, Six workers can finished one 3K*10K standard prefab house.
C. Beautiful appearance: The whole house is bright and colorful with smooth surface.
D. Flexible layout: The door and window can be loaded randomly and the partition wall can be put in any position of the lateral axis. The stair can be put outside.
E. Waterproof structure: The house is designed to be waterproof, no need for extra waterproof treatment.
F. Long life span: The light steel structure has been treated by the anti-rust spray paint. It can be used for 10 years at least if used properly.
G. Environmental friendly: Reasonable design, easy to reassemble, can be repeatedly used, little wastage, no building garbage. The average annual cost fot using this type of house is much lower than the one made by other material.
H. The houses are made of standard size or customized.
If you really interested in our steel structure building, and would like we do the design for youplease give me the following information:
1. Dimension: Length, width, height, eave height, roof pitch, etc.
2. Doors and windows: Dimension, quantity, position to put them.
3. Local climate: Wind speed, snow load, etc.
4. Insulation material: Sandwich panel or steel sheet.
5. Crane beam: Do you need crane beam inside the steel structure? And its capacity.
6. Is there any materials that are not allowed to import into the country where the structure
is planning to use?
7. If you have other requirements, such as fire proofing, isolated roof, etc, please also
inform us.
8. It's better if you have your own drawings or pictures. Please send them to us.
