Specifications
polycarbonate panels1.100% virgin raw material
2.UV & 10 yrs quality guarantee
petitive price
4.good connetors
u-lock polycarbonate sheet
Gensin U sheet is an advanced construction system , its design has been proved it combined good lighting , heat insulation and high impact resistance features. I t provides a l.ight , non heat expansion and no leakge design , can bearing a very high weight loads. Advantages of Lixin systems make it a good choice for long-time use .
Product features :
- Light weight
- High impact strength
- Fire retardancy
- Good light transmission
- With UV protection and thermal insulation
- Excellent physical, mechanical, and electrical properties
- Inhibits condensation
- Customized dimensions
- Simply processed and installed
STRUCTURE | THICKNESS(mm) | WEIGHT (kg/sqm) | WIDTH(mm) | U-VALUE (W/m2K) | LIGHT TRANMISSION(%) |
4wall rectangle | 6 | 1.7 | 600 | 2.63 | 76 |
8 | 1.9 | 2.57 | 73 | ||
10 | 2.2 | 2.41 | 70 | ||
4wall honeycomb | 8 | 2.1 | 2.45 | 72 | |
10 | 2.4 | 2.16 | 69 | ||
12 | 2.6 | 1.98 | 68 | ||
6wall diamond | 14 | 3.1 | 800 | 1.81 | 69 |
16 | 3.3 | 1.62 | 67 | ||
18 | 3.6 | 1.53 | 65 | ||
7wall diamond | 18 | 3.8 | 1040 | 1.51 | 60 |
20 | 4.1 | 1.48 | 59 | ||
22 | 4.3 | 1.45 | 57 | ||
25 | 4.5 | 1.39 | 55 | ||
5wall honeycomb | 25 | 4.5 | 1.31 | 53 | |
28 | 4.8 | 1.29 | 51 | ||
30 | 5 | 1.27 | 48 |
Mostly excellence:
- Withstand very high loads
- No thermal expansion
- Simple and quick to install
- Prevent leakage
- Thermal protection and insulation
- Suitable for bending design
- Intellective & light control series products
Property | method | conditions | units | Value |
Density | D-790 |
| g/cm3 | 1.2 |
Heat deflection temperature (HDT) | D-648 | Load:1.82Mpa | °C | 130 |
Service temperature- short term |
|
| °C | -50-120 |
Service temperature –long term |
|
| °C | -50-100 |
Coefficient Of Linear Thermal Expansion | D-696 |
| cm/cm°C | 6.5*10-5 |
yield strength | D-638 | 10mm/min | Mpa | 62 |
elongation at break | D-638 | 10mm/min | % | >80 |
falling weight impact test | ISO 6603/1 |
| J | 40-400 |
hermal expansion, contraction rate |
|
| mm/m | 3 |
Applications :
- Business and retail building
- Sporting roofing
- With canopy footway
- Fairground
- Service station
- Entrance
- Natatorium roofing
