Specifications
3mm Polycarbonate Sheet Pricehigh impact resistance
very competetive price
Haining 10-year Guarantee 3mm Polycarbonate Sheet Price
General solid polycarbonate sheet has the strength of light and durability, high light transmittance, execellent impact resistance, good weather resistance and simply installed. The weight is less than half of the glass. The sheets are widely used in construction and skylight, roofings decoration and so on.
Specifications:
Thickness: 0.8 to 16mm
Maximum width: 2,100mm
Length: any dimension
Specific gravity: 1200kg/cbm
Colors: clear, blue, green, opal, brown,bronze,etc.
Technical features:
Impact strength: 850J/m ,the impact strength of solid PC sheets is 250 times
that of glass, 20-30 times of PMMA sheet
Light transmission: 80%-90% for different thickness of clear color
UV resistance:with our 50μm thickness UV layer ,the sheet can filter 99% ultraviolet radiation in sunlight
Specific gravity: 1.2 g/cm
Coefficient of thermal expansion: 0.065 mm/moC
Temperature: -40oC to 120oC
Heat conductivity: 2.3-3.9 W/m2 oC
Tensile strength: >60N/mm2
Flexural strength: 100N/mm2
Modulus of elasticity: 2,400mPa
Tensile street at break: >65mPa
Elongation at break: >100%
Specific heat: 1.16J/kgk
Heat deflection temperature: 140oC
Soundproof index:6mm--29dB,8mm--31dB,10mm-32dB 12mm--34dB
Specification of polycarbonate solid sheet:
|
Thickness (mm) |
Standard Width(mm) |
Stand Length (mm) |
Specific Gravity |
Standard Color |
| 0.8 | ||||
| 1 | ||||
| 1.5 | ||||
| 1.8 | ||||
| 2 | clear | |||
| 2.5 | green | |||
| 3 | 1200-2100 | 6000 | 1.2kg/m² | blue |
| 4 | grey | |||
| 5 | brown | |||
| 6 | opal | |||
| 7 | ||||
| 8 | ||||
| 10 | ||||
| 12 |
Solid Polycarbonate Sheet
Color and transmittance |
||||
Thickness |
4(mm) |
6(mm) |
8(mm) |
10(mm) |
transparent |
82% |
81% |
80% |
79% |
green |
53% |
49% |
45% |
42% |
blue |
32% |
28% |
25% |
22% |
opal |
27% |
21% |
19% |
16% |
brown |
35% |
31% |
25% |
22% |
lake blue |
57% |
525% |
48% |
47% |
Features of polycarbonate sheet:
- Impact strength: the impact strength of solid PC sheets is 250 times that of glass, and the impact strength of hollow PC sheets is 80 times that of glass
- Light weight: the weight of a solid PC sheet is only about half of glass, and the weight of a hollow PC sheet is only about one twelfth at the same thickness
- Transparency: the light transmission of a 3mm solid PC sheet is 88%, and the light transmission of a 6mm hollow PC sheet is 80%
- UV-protection: a PC sheet is co-extruded with a high-density ultra violet ray that also keeps the PC sheet from discoloring
- Resistance to weather: a PC sheet has resistance to bad weather and maintains excellent properties in a wide temperature range from -40 to 120oC
- Inhibiting condensation: when the outdoor temperature is 0oC and the indoor temperature is 23oC, the PC sheet will be condensation up to 80% humidity
- Thermal insulation: the K-value of glass is 1.2 times that of solid a PC sheet and is 1.7 times that of a hollow PC sheet. PC sheets saves energy while preventing heat loss
- Sound insulation: the hollow form and polycarbonate resin offers significant advantage to that of glass
- Flame resistance: through testing by the National Center for Quality Supervision and Testing of fire building materials, the material is rated as class B1 according to QB8624-1997 standards
- Easy installation: a PC sheet can be bent while hot or cold and can be used on curved roves and windows. The minimum radius of curvature of a PC sheet is 175 times of its thickness.
pix de Policabonato
Technical features:
- Impact strength: 850J/m
- Light transmission: 88%
- Specific gravity: 1.2 g/cm3
- Coefficient of thermal expansion: 0.065
- Temperature: -40 to 120oC
- Heat conductivity: 2.3-3.9 W/m2
- Tensile strength: >602
- Flexural strength: 1002
- Modulus of elasticity: 2,400Mpa
- Tensile street at break: >65Mpa
- Elongation at break: >100%
- Specific heat: 1.16J/kg.K
- Heat deflection temperature: 140oC
- Soundproofing: (6mm solid): 20dB
Gensin Solid PC Application:
- Lighting
- Indoor windows and doors
- Riot windows, shop show window
- Show box, Observe window
- Awning, carport
- Indoor partition
- Advertising panel
- Soundbarrier
