Specifications
1mm Polycarbonate Solid Sheethigh impact resistance
10-year quality warranty
100%Sabic/Bayer virgin materia
1mm Polycarbonate Solid Sheet 1220mm*2440mm Heat Formed Plastic Panels
Specifications:
Thickness: 0.8 to 20mm
Maximum width: 2,100mm
Length: any dimension
Specific gravity: 1200kg/cbm
Colors: clear, blue, green, opal, brown,bronze,etc.
|
Thickness (mm) |
Standard width (mm) |
Standard length (mm) |
Standard gravity (kg/sqm) |
Standard colors |
1.5 |
1200-2100
|
6000mm 4mm≥no limited |
1.8 |
Clear Green-blue Blue Green Brown opal |
1.8 |
2.16 |
|||
2 |
2.4 |
|||
2.5 |
3.0 |
|||
3 |
3.6 |
|||
4 |
4.8 |
|||
5 |
6.0 |
|||
6 |
7.2 |
|||
8 |
9.6 |
|||
10 |
12 |
|||
12 |
14.4 |
Technical features:
Impact strength: 850J/m ,the impact strength of solid PC sheets is 250 times
that of glass, 20-30 times of PMMA sheet
Light transmission: 80%-90% for different thickness of clear color
UV resistance:with our 50μm thickness UV layer ,the sheet can filter 99% ultraviolet radiation in sunlight
Specific gravity: 1.2 g/cm
Coefficient of thermal expansion: 0.065 mm/moC
Temperature: -40oC to 120oC
Heat conductivity: 2.3-3.9 W/m2 oC
Tensile strength: >60N/mm2
Flexural strength: 100N/mm2
Modulus of elasticity: 2,400mPa
Tensile street at break: >65mPa
Elongation at break: >100%
Specific heat: 1.16J/kgk
Heat deflection temperature: 140oC
Soundproof index:6mm--29dB,8mm--31dB,10mm-32dB 12mm--34dB
Solid Polycarbonate Sheet
Color and transmittance |
||||
Thickness |
4(mm) |
6(mm) |
8(mm) |
10(mm) |
transparent |
82% |
81% |
80% |
79% |
green |
53% |
49% |
45% |
42% |
blue |
32% |
28% |
25% |
22% |
opal |
27% |
21% |
19% |
16% |
brown |
35% |
31% |
25% |
22% |
lake blue |
57% |
525% |
48% |
47% |
Applications
1. Lighting
2. Indoor windows and doors
3. Riot windows, shop show window
4. Show box, observe window
5. Awning, carport
6. Indoor partition
7. Advertising panel
8. Sound barrier
