ISO9001 Certificate Smooth Surface PVC Pipe
USD $1 - $2
/ Meter
3000 Meters(Min.Order)
- 20000 Meter / Meters per Month
- Tianijn
- T/T Credit Card
You May Like
Product Details
Brand Name: | Fosite, fosite | Model Number: | ST1005 | Material: | Other, PVC, PVC |
Specification: | 20 to 630mm, 1/2"-4" | Length: | 4m | Thickness: | 2.0mm--4.9mm, Customized, As requirement |
Standard: | ISO1452 GB/T10002, DIN 8077 |
Product Description
Sizes
PVC inside (mm) | SIZE | Diameter CNS standard | JIS standard | DIN standard | ANSI | BS | |||
(inch) | outside diameter (mm) | wall thickness (mm) | outsidewall diameter (mm) | wall thickness (mm) | outsidewall diameter (mm) | wall thickness (mm) | outside diameter (mm) | outside diameter (mm) | |
10 | 3/8 " | 18±0.2 | 2.2±0.6 | 18±0.2 | 2.5±0.2 | 16±0.2 | 17.14 | 17.14 | |
15 | 1/2 " | 22±0.2 | 2.7±0.6 | 22±0.2 | 3.0±0.3 | 20±0.2 | 3.0±0.3 | 21.34 | 21.34 |
20 | 3/4 " | 26±0.2 | 2.7±0.6 | 26±0.2 | 3.0±0.3 | 25±0.2 | 3.0±0.3 | 26.67 | 26.67 |
25 | 1 " | 34±0.2 | 3.2±0.6 | 32±0.2 | 3.5±0.3 | 32±0.2 | 3.5±0.4 | 33.4 | 33.4 |
32 | 1+1/4 " | 42±0.3 | 3.2±0.6 | 38±0.3 | 3.5±0.3 | 40±0.2 | 3.5±0.4 | 42.16 | 42.16 |
40 | 1+1/2 " | 48±0.4 | 3.6±0.8 | 48±0.4 | 4.0±0.4 | 50±0.2 | 4.0±0.4 | 48.26 | 48.26 |
50 | 2 " | 60±0.5 | 4.1±0.8 | 60±0.5 | 4.5±0.4 | 63±0.3 | 4.5±0.4 | 60.32 | 60.32 |
65 | 2+1/2 " | 76±0.5 | 4.1±0.8 | 76±0.5 | 4.5±0.4 | 75±0.3 | 4.5±0.4 | 73.02 | 73.02 |
80 | 3 " | 89±0.5 | 5.1±0.8 | 89±0.5 | 5.9±0.4 | 90±0.3 | 5.9±0.4 | 88.9 | 88.9 |
100 | 4 " | 114±0.6 | 6.6±1.0 | 114±0.6 | 7.1±0.5 | 110±0.3 | 7.1±0.5 | 114.3 | 114.3 |
3. Application:
1.Soil and waste discharge pipelines (low and high temperature) inside buildings
2.Rainwater pipelines inside the building
3.Buried drainage pipelines without pressure on the ground
4. Municipal water supply, Industrial liquids transportation
