Home > Products > PPR PIPING SYSTEM > China Manufacturer Hot & Cold Water Pipe for PPR Pipe
China Manufacturer Hot & Cold Water Pipe for PPR Pipe
- XINGANG
You May Like
Product Details
Place of Origin | Hebei, China | Brand Name | fosite, fosite | |
Model Number | ST1002, ST1002 | Material | Other, ppr, PPR | |
Specification | 20mm--160mm, 20mm-160mm for ppr pipe | Length | 4M or as required, 4M or as required | |
Thickness | 2.3mm, many kinds | Standard | DIN8077/8078, din8077/8078 for ppr pipe |
Product Description
Specifications
ppr pipe hot water pipe
1.OD(mm):20-160
2.Friendly for environment
3.Light weight,easy to install
ppr pipe hot water pipe
S5(PN1.25) | S4(PN1.6) | S3.2(PN3.2) | S2.5(PN2.5) |
| 20*2.3 | 20*2.8 | 20*3.4 |
25*2.3 | 25*2.8 | 25*3.5 | 25*4.2 |
32*3.0 | 32*3.6 | 32*4.4 | 32*5.4 |
40*3.7 | 40*4.5 | 40*5.5 | 40*6.7 |
50*4.6 | 50*5.6 | 50*6.9 | 50*8.4 |
63*5.8 | 63*7.1 | 63*8.6 | 63*10.5 |
75*6.9 | 75*8.4 | 75*10.3 | 75*12.5 |
90*8.2 | 90*10.1 | 90*12.3 | 90*15 |
110*10.1 | 110*12.3 | 110*15.1 | 110*18.3 |
Material: first class Random Polypropylene
Sizes: 20mm to160mm
Pressure Rating: 1.25MPa, 1.6MPa, 2.0MPa ,2.5MPa
Colors: light grey, white or other colors on request
Connection: socket fusion joint, electro fusion joint or transition joint
Applications: Cold or hot water supply, heating system including flooring heating, wall heating and radiating system, Central air conditioning system, industrial liquids transportation
Products Advantages:
1. High Temperature Resistance: the maximum sustained working temperature is up to 70 Degrees Celsius, the maximum transient temperature is up to 95 Degrees Celsius
2. Heat Preservation: low thermal conductivity which is only 1/1500 of brass pipe, and 1/250 of steel pipe
3. Non-toxic: no heavy metal additives, would not be covered with dirt or contaminated by bacterium
4. Corrosion Resistant: resist chemical matters or electron chemical corrosion
5. Lower Installation Costs: light weight and ease of installation can reduce installation costs by as much as 50% over metal piping system
6. Higher Flow Capacity: smooth interior walls result in lower pressure loss and higher volume than metal pipes
7. Long Life: more than 50 years under normal conditions
8. Recycled and Environment-friendly.
