10Bar PP Fittings /pp Compression Fittings

Name: 10Bar PP Fittings /pp Compression Fittings
Brand: Fosite
SKU: 141832258
Availability: InStock

US$ 0.01 - 0.02 MOQ: 1500 Pieces

Key Specifications

Material:

Plastic

Technics:

Casting

Type:

Tee

Shijiazhuang Shentong Plastic Industry Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin & Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Material Plastic

Technics Casting

Type Tee

Place of Origin Hebei, China

Model Number STPP

Brand Name Fosite

Connection Female

Shape Other, Round

Head Code Other, Round

10Bar PP fittings /pp compression fittings

Product Description

		Name	10Bar PP fittings /pp compression fittings
		Body(A)	Heterophasic block polypropylene co-polymer(PP-B) of exceptional mechanical properties even at high temperature.
		Blocking bush(D)	Polypropylene
		Nut(B)	Polypropylene with dye master of high stability to UV rays andsolidity to heat( S grade according to standard DIN54004)
		Clinching ring(C)	Polyacetal resin(POM)with high mechanical resistance And hardness
		O Ring gasket(E)	Special elastomeric acrylonitrile rubber(EPDM) for alimentary use
		Reinforcing ring	AISI 430 (UNI X8Cr17,W,nr 14828)Stainless steel for female threads from 1”to 4”
Standard	ASTM D2466,ASTM D2665 , BS4346, NBR5648,DIN
Machines	injection machines
Working place	200PSI@73° F(23°C)
Warranty	at least 50 years
Size	20-110mm
Pressure rate	up to 16 bar (kg/ sq. cm).

Model NO.	diameter(mm)	Package Quantity in one CTN(pcs)	package gross weight(kg)	package net weight(kg)	PACKING SIZE(mm)
PFI099	20*1/2	252	23	22	580410330
PFI100	25*1/2	168	20.5	19.5	580410330
PFI101	25*3/4	168	21.5	20.5	580410330
PFI102	32*3/4	105	21	20	580410330
PFI103	32*1	105	22.5	21.5	580410330
PFI104	40*1-1/4	40	24.5	23.5	580440350
PFI105	50*1-1/2	40	24.5	23.5	580440350
PFI106	63*1-1/2	24	21.5	20.5	540530330
PFI107	63*2	24	21.5	20.5	540530330
PFI108	75*2-1/2	12	29	28	670370450
PFI109	90*3	12	29	28	670370450
PFI110	110*4	8	24.5	23.5	580440350
