HDPE Equal Tee Plastic Pipe Fittings manufacturer
PE pipe fittings is light, which is more common for partial application pe80 pe100 grade level and two standards , including :
PE80 density of about 0.94 g / cm 3, PE100 density of about 0.96 g / cm 3 ;
Easy thermoplastic - easy to process ( such as injection molding, extrusion molding
Remanufacturing easy recycling
Good resistance to radiation and chemical stability
Good resistance to cold , the temperature can be -40 ℃ to
Excellent electrical insulation properties , is not affected by electrolytic corrosion
Malleable - extended break PE80> 700% PE100> 600%
Anti- erosion resistance - 8 times better than steel
Approximately half of the low thermal conductivity of glass
Smooth surface , unlike the role of metal pipes rust easily with oxygen crusts
pe pipe connection into fused pipe connections and fittings connected to melt , the more ordinary side, the other , as well as socket connections, this method is applied to a small size.
1 , fused connection : Follow these steps: First check , and then is cut pipe , pipe fittings joints clean , scrape the oxide layer , connecting the two parts of the tube and pipe fittings , calibration welder , welding parameter adjustment in accordance with the welding voltage, welding Dimensions , electricity, welding, and then finally cooled.
2, the hot melt connection : the inner surface of the pipe surface and the pipe is inserted while the welding is non-rotating die head is heated for a few seconds , then quickly removed and welding device , the heat pipe has a fast vertical insertion tube , packing, cooling to .
3 , socket connections, relatively simple, not elaborate here .
Material: 100% new material PE80 or PE100
Working Medium: Water and Gas
Working Pressure: 0.3Mpa~1.6Mpa
Working Temperature: -40℃~40℃
Specifications: Dn40 ~ Dn630
New mould and scientific design
Competitive price and accept OEM
Recycled and Environment-friendly
Color: black or other colors on request
Guarantee period : more than 50 years under proper use
***Basic performance of raw materials for pipe fittings
| Paramenter | Units | Requirement | Test Value |
| Density | kg/m³ | ≥930 | 23ºC |
| Melt flow rate | g/10min | 0.2~1.4 | 190ºC,5kg |
| Thermal slaility (OIT) | min | >20 | 200ºC |
| Volati lematter content | mg/kg | ≤350 | |
| Moisture content | mg/kg | ≤300 | ASTM D 4019:1994a |
| Carbon black content | % | 2.0~2.5 | |
| Crbon black dispersion | grade | ≤3 | |
| Gas proof components | h | ≥20 | 80ºC,2MPa(Hoop stress) |
|
Resistance to slow crack growth (En>5mm) |
h | 165 |
80ºC,0.80MPa(Testing pressure) 80ºC,0.92MPa(Testing pressure) |
OTHER RELATIVE PE PIPE FITTINGS
FAQ
Q:What material are you specializedin?
A: We manufacture PP-R, HDPEpipes and fittings.
Q: Please tell me your largest outer diameterfor pipes.
A:We can produce 1600mm diameter as the largest size.
Q: The price of your products is higher than others.
A: We can't promise you the best price, but we can promise you the best quality. We import raw material from famous companiessuch as LG Chemical, Iydellbasell, Chervrom, Sinopec.
Q: For pipe fittings, what do you domainly?
A: For fittings,coupling, elbows, tee, reducer, valve and cap are our mainproducts.
Q:Where is your factory located in?
A: Our factory located in Shijiazhuang City, which is only 2 hours away from Beijing air port.
Q: Can you provide us some samples for testing?
A:Of course, my friend. For small amount of samples, we can provide you for free.
Q: How is our customer service?
A: allour sales representatives can speak fluent English. They will answer all of your questions in 24hours.
1.How to get free samples ?
A: Send your address ,your telphone number ,post code ,and express account number to our mail box .and told us which model of samples you need .
2.Who pay for the express cost ?
A: We can support you free samples each model 1-3 pcs ,and we do not pay for express cost .
3.What is your packing?
A: usually plastic bags,carton,can be packed as your require.
1 Genuine produces with excellent quality and competitive price.
2 Cooperating with the customers all over the world and knowing the markets very well.
3 After- Services will be highly-satisfied. Any problems and feedbacks will be answered in a short of time.
