STSJ-3 Lab Sieve Shaker

STSJ-3 Lab Sieve Shaker thumbnail-1
STSJ-3 Lab Sieve Shaker photo-1
US$ 368 - 589 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
SHTG
Model Number:
STSJ-3
Contact Supplier Request Quote Chat Now
Shanghai Civil & Road Instrument Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name SHTG
Model Number STSJ-3
Power Electronic
Usage Other, accurate seperation of materials

Specifications

Lab Sieve shaker
1.Side locking driven motor saving space .
2.Sturdy basement supporting whole vibrating device



STSJ-4A High Frequency Sieve Shaker- Analytical sieve shaker

STSJ-3 Lab Sieve shaker





Application:



The GSZ-1 High-frequency Sieve Shaker is mainly used for graded analysis of non-cohesive and dry grain substance(soil material).



Specifications:

1. Shaking frequency: 2500/min
2. Shaking method: up and down
3. Shaking amplitude: 1.5mm
4. Time setting: 0 – 60min. selectable
5. Motor power: 25W
6. Sieve size: 200 x 50mm (9 level) or 300 x 75mm  (7 level)
    sieve opening: 20 – 0.75mm
7. Power supply: 220V 50Hz
8. Dimension: 430 x 430 x 750mm3
9. Weight: 16kg



STSJ-4 Digital display high frequency sieve shaker- Analytical sieve shaker

STSJ-3 Lab Sieve shaker





Applications:



The Machine is used in sieve analysis of materials in laboratory and widely used in Geology, Metallurgical industry, Chemical industry, Building industry, Coal industry, National defense, scientific research, Grinding wheel manufacturing and cement industry etc..



Specifications:



1. Diameter of sieves to be used: 300mm or 200mm

2. Overlapping height of sieves: 440mm

3. Amplitude of sieve base: 8mm   4. Shaking frequency: 221times/min

5. Shaking compacting times: 147times/min.

6. Slewing radius: 12.5mm;     7. Power of motor: 0.37kW  1400rpm

8. Dimension: 600 x 400 x 880mm (L x W x H)   9. Weight: 130kg



Main Features:



Side locking driven motor saving space .

Sturdy basement supporting whole vibrating device

Three dimensional frame structure locking testing sieves

Digital display device showing shaking times and time

High quality fasten jigs locking testing sieves



Order information:



1.     You should buy additional testing sieves separately.

2.     Additional testing sieve with 200mm or 300mm diameter



STSJ-3 Laboratory sieve shaker-  Lab Sieve shaker

STSJ-3 Lab Sieve shaker







Specifications

Lab Sieve Shaker
1.Side locking driven motor saving space .
2.Sturdy basement supporting whole vibrating device



Applications:



The Machine is used in sieve analysis of materials in laboratory and widely used in Geology, Metallurgical industry, Chemical industry, Building industry, Coal industry, National defense, scientific research, Grinding wheel manufacturing and cement industry etc..



Specifications:



1. Diameter of sieves to be used: 300mm or 200mm

2. Overlapping height of sieves: 440mm

3. Amplitude of sieve base: 8mm   4. Shaking frequency: 221times/min

5. Shaking compacting times: 147times/min.

6. Slewing radius: 12.5mm;     7. Power of motor: 0.37kW  1400rpm

8. Dimension: 600 x 400 x 880mm (L x W x H)   9. Weight: 130kg



Order information:



1.     You should buy additional testing sieves separately.

2.     Additional testing sieve with 200mm or 300mm diameter .
