Fireplace Gas Valve Control System

Specifications

1. Remote Control
2. CE & UL & CSA Approved
3. For fireplace and BBQ
4. Both NG & LPG
5. With Gas valve & Ignition

Fireplace Gas Valve Control System with Remote Controller (BK-368)



Hot Point :

1. Remote Controlled
2. For fireplace and BBQ
3. Both NG & LPG
4. Includes of Gas valve & Ignition

5. CE & UL & CSA Approved



Specification :

1. Gas Type: Both Natural Gas & LPG (Propane)

2. Capacity: Can be adjusted by your market needs

           NG  : Max 45000 BTU / hr

           LPG :  Max 90000 BTU / hr

3. Temperature : ~ 80^.C (175^.F)

4. Operation Voltage : 110 / 220 VAC ; 3 VDC

5. Output Voltage : 12 kV / min

6. Ignition Circles : 6 Hz at 3VDC

7. Maximum Operation Pressure : 1 / 2 psi (3.5 kpa)

8. Flame Faliure Respone Time : 25 +/- 5s  (safty control system).
