Temperature/Humidity Transmitter

Name: Temperature/Humidity Transmitter
Brand: Tongdy
SKU: 141811186
Availability: InStock

Tongdy Sensing Technology Corporation (Beijing)

US$ 25 - 35 MOQ: 50 Pieces

Key Specifications

Place of Origin:

Beijing, China

Brand Name:

Tongdy

Model Number:

F2000TSM-TH

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Beijing, China

Brand Name Tongdy

Model Number F2000TSM-TH

Usage Indoor

Theory Temperature Controller

Temperature Range 0~50C

	Temperature	Relative Humidity
Sensing element:	Band-gap-senor	Capacitive humidity sensor
Measuring range	0°C~50°C(32°F~122°F) (default)	0 -100%RH
Accuracy	±0.5°C (20~40°C)	±3%RH (25°C, 35%-65%RH)
Stability	±0.1°C per year	±1%RH per year
Storage environment	10~50°C(-40~158°F)/ 10~70%RH
Connection	Screw terminals
Set measurement zone	The zero and the end can be set via Modbus
Housing/IP Class	PC/ABS fireproof material/IP 40
Output	0~10VDC(default) or 4~20mA (selectable by jumpers) 0~5VDC (selected at place the order)
Power supply	24V DC or 24V AC ±20%
Power cost	≤2W
Resistance permitted	≤500Ω

Designed for transmit relative humidity measurement and temperature measurement
Wall mounting type and duct type selectable
0 to 10V DC/0 to 5V DC/4 to 20mA outputs
Two temperature ranges selectable in orders
Humidity output: automatically corrected over the full range of operating conditions
One point field of temperature and humidity measurement modification
RS485 communication is optional
