Help CenterDuct Mounting Temperature Humidity Controller for Ventilation Systems
Related Products
-
Split Temperature Humidity Controller for Ventilation SystemsNegotiableMOQ: 10 Pieces -
Hot Selling!!temperature & Humidity SensorNegotiableMOQ: 10 Pieces
-
Digital Room Temperature Humidity Controller for Cooling/Heating DeviceNegotiableMOQ: 100 Pieces
-
Special Split Temperature Humidity ControllerNegotiableMOQ: 10 Pieces
-
Wholesale Temperature Humidity ControllerUS$ 1 - 2MOQ: 10 Pieces
Specifications
Control temperature and humidity devicesCE Certificate
High end HVAC systems
Duct/wall /wireless /split mounting
Duct Mounting Temperature Humidity Controller for Agriculture
u Designed for detection temperatureand relative humidity
u High accuracy sensors with combined temperature andrelative humidity together with the digital auto
compensation
u Outside sensing probe design for measurements more accurate,no influence from components
heating
u Special white backlit LCD can be selected with displayingboth actual humidity and temperature
u Smart structure for easy disassembly
u Provide three types of wall mounting and duct mounting, andsplit type
u Provide up to two dry contactoutputs with each 5amp
u Friendly operation buttons forsetup and operating
u Modbus RS485 communication optional
u ZigBee wireless optional
u CE-Approval
Temperature Humidity Controller Typical Applications
u High end HVACsystems
u Ventilation systems
u Detection and display temperatureand RH measurements
u Control temperature and humidity devices
u Modbus communication systems
u Wireless receiving and transmissionof temperature& RH
Specifications
|
Temperature |
Humidity |
Accuracy |
±0.5°C (20~40°C) |
±4.5%RH (25°C, 15%-85%RH) |
Measuring range |
-20°C~60°C(default) 0°C~50°C 0°C~60°C selectable in orders |
0 -100%RH |
Display resolution |
0.1°C |
0.1%RH |
Stability |
±0.1°C |
±1%RH per year |
Storage environment |
10°C-50°C, 20%RH~60%RH non condensing |
|
Connection |
Screw terminals/ wire diameter:1.5mm2 |
|
Housing |
PC/ABS fireproof material |
|
Protection class |
IP40 |
|
Output |
2X5Amp dry contacts |
|
RS485 interface (option) |
Modbus RS485 interface optional |
|
Wireless module (option) |
ZigBee protocol |
|
Power supply |
24VAC±10% or 230VAC±10%selectable |
|
Power cost |
230V: ≤2.8W; 24V: ≤2.0W |
|
Dimension |
Wall mounting: 85(W)X100(H)X50(D)mm+65mm(extend outside)XÆ19.0mm Duct mounting: 85(W)X100(H)X50(D)mm +135mm (sensor probe)XÆ19.0mm |
|
Net weight |
Wall mounting: 280g Duct mounting: 290g |
|
