Specifications
1. Digital Temperature and humidity controller2.2Xon/off output
| Power supply | 230VAC/110VAC/24VAC selectable at placing the order |
| |||
| Output | F2000LB-H1: triac resource output F2000P-TH series: 5A relay for the On/Off output F2000PC-TH-K01/K02: 5A relay for the On/Off output |
| |||
| Displaying | LCD |
| |||
| Connection length between the controller with the external sensor box | Maximum 100 meters |
| |||
| Net weight of the controller | F2000LB-H1: 230g F2000P-TH Series: 280g | ||||
| Dimensions | F2000LB: 120mm(L)×90mm(W)×24mm(H) F2000P-TH: 120mm(L)×90mm(W)×32mm(H) | ||||
| Mounting standard | Wall mounting in the wire box of 2”×4” or 65mm×65mm | ||||
Sensors spec. | Temperature | Humidity |
| |||
Accuracy | ±0.5°C ±0.4°C -high accuracy version | ±3%RH (30%-70%RH) ±2.5% RH (20%-80%RH)- high accuracy version |
| |||
Measuring range | 0°C~60°C | 0~100%RH-high version |
| |||
Display resolution | 5°C 0.1°C-high version | 1% RH 0.1%RH-high version |
| |||
Stability | ±0.1°C | ±1%RH per year |
| |||
Storage environment | 10°C-50°C, 10%RH~80%RH |
| ||||
1.Designed for monitoring and control the ambiance relative humidity by control a humidifier or
dehumidifier
2.Temperature detection and control optional
3.Microprocessor makes detection and controlling more accurately
4.LCD can display working status such as %RH, temperature, set point, and device mode, etc. Makes reading and operating easy and accurate
5.All models feature user-friendly setting buttons
6.Enough parameters setup let the controller meeting wide range application. All setup will be held even if them power failure
7.Lock function avoids wrong operation and makes setting to be held
8.Especially provide two models with 8A outlet current to connect the humidity device directly. Both wall mounting type and convenient plug-and-play type selectable.
9.Infrared Remote Control (optional)
10.Blue backlight (optional)
11.RS 485 communication interface (optional)
12.External sensors (optional)
13.We also provide smart hygrostat with mould-proof function, please see F2000LB-HygroPro Datasheet
14.For humidity & temperature transmitters, please see F2000TSM-TH series
