Specifications
co2 monitoring and controller: co2.temperature,humidityNDIR infrared CO2 module
application widerly
School classroom co2 monitoring and controller
co2 monitoring and controller Description:
F2000IAQ-CO2 detector/Indicator is used to monitor and alarm CO2 level and room temperature. Relative humidity detection and display can be as an option. Other options can be provided to users: RS485 communication interface with independent address;one dry contact output to control a ventilation device.
Especial design for schools, kindergartens, office buildings, conference rooms, rest rooms as well as other public places.
Built-in NDIR CO2 module, 15 years long life.
ABC Logic self calibration algorithm for CO2 sensor.
Real-time detect and display room CO2 and temperature
3 LED indicator lights following three different CO2 ranges to indicate
ambiance ventilation situation: Optimal Ventilation; Poor Ventilation and Insufficient Ventilation.
Optional humidity detection and display
co2 monitoring and controller Features
Real-time detecting and display CO2 level during 0ppm to 20,000ppm CO2 range; Also detecting room temperature from 5 to 45°C
Optional real-time humidity from 5%RH to 95%RH
NDIR CO2 sensor technology of infrared self diffusion
Self Calibration Algorithm makes it in using without calibration amending
The three measured CO2 ranges for 3-LED indicator lights selectable by end users
LED’s brightness adjustment Optional 1X dry contact output or one 0~10VDC output to control a ventilation device
Easy preset CO2 level for buzzer alert (optional)
Optional RS485 interface to connect to a PC or another system (optional)
