Home > Instruments & Meters > Meter for Liquid & Gas > Thermometer & Hygrometer > Top Digital Room Thermostatfor for VAV Terminal

Top Digital Room Thermostatfor for VAV Terminal

Name: Top Digital Room Thermostatfor for VAV Terminal
Brand: Tongdy
SKU: 141810394
Availability: InStock

Top Digital Room Thermostatfor for VAV Terminal thumbnail-1

Top Digital Room Thermostatfor for VAV Terminal photo-1

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Beijing, China

Brand Name:

Tongdy

Model Number:

F2000LV-A

Contact Supplier Request Quote Chat Now

Tongdy Sensing Technology Corporation (Beijing)

Payment & Shipping

Payment Methods:

Port of Shipment:

Beijing

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Beijing, China

Brand Name Tongdy

Model Number F2000LV-A

Usage Indoor

Theory Temperature Sensor

Accuracy ±0.5 ℃ (±1℉) @25℃

Temperature Range 5~35C

Specifications

Room thermostat with propotional-action control for VAV systems

Top Digital Room Thermostat for for VAV Terminal

Digital Room VAV Thermostat Features

u Designed to control the room temperature for VAV terminals with 1X0~10 VDC output to cooling/heating or 2X0~10 VDC outputs to cooling and heating dampers. Also one or two relay outputs to control one or two stages electric aux. heater.

u LCD can display working status such as room temperature, set point, analog output, etc. Makes reading and operating easy and accurate.

u All models feature user-friendly setting buttons

u Smart and enough advanced setup makes the

thermostat being used in all

u Up to two-stage electric aux. heater control makes temperature controlling more accurate and energy-saving.

u Large set point adjustment, the mini. and max. limit of temperature preset by end users

u Low temperature protection

u Celsius or Fahrenheit degree selectable

u Cooling/heating mode auto changeover or manual switch selectable

u 12 Hours Timer Option can be preset 0.5~12 hours to turn off the thermostat automatically

u Two parts structure and quick wire terminal blocks make mounting easily.

u Infrared Remote Control (optional)

u Blue backlight (optional)

uOptional Modbus communication interface

Specifications

Power supply	24 VAC±10% 50/60HZ 18VDC~36VDC
Electrical rating	2 amp load per terminal
Sensor	NTC 5K
Temperature control range	5-35℃ (41℉-95℉)
Accuracy	±0.5℃ (±1℉) @25℃
Analog output	One or two analog outputs Voltage DC 0V~DC 10 V Current 1 mA
Protection class	IP30
Environment condition	Operating temperature: 0 ~ 50℃(32~122℉) Operating humidity: 5 ~ 99%RH Non condensing Storage temperature: 0℃~50℃(32~122℉) Storage humidity: <95%RH
Display	LCD
Net Weight	240g
Dimensions	120mm(L)×90mm(W)×24mm(H)
Material and colors:	PC/ABS Fireproofing house with white color
Mounting standard	Mounting on the wall, or 2“×4“/ 65mm×65mm pipe box

¨ Models

Type	Model	Characteristic
VAV Room Thermostat Power supply: 24VAC/VDC	F2000LV-A-N	1X 0~10V output for an actuator of VAV terminal with cool/heat manual switch
	F2000LV-A01	1X 0~10V output for an actuator, 1X on/off contact output to a heater. Cool/heat manual switch.
	F2000LV-A02	1X 0~10V output for an actuator, 2X on/off contact outputs for 2-stage heater. Cool/heat manual switch
	F2000LV-A-Pro	1X 0~10V output for an actuator, an external sensor detects air duct temperature to change cool/heat automatically. Cool/heat changeover or manual switch can be selected.
	F2000LV-A01-Pro	1X 0~10V output for an actuator, 1X on/off dry contact output to a heater with an external sensor detects air duct temperature to change cool/heat automatically. Cool/heat changeover or manual switch can be selected.
	F2000LV-A-D	2X 0~10V outputs for cooling and heating dampers
	F2000LV-A01-D	2X 0~10V outputs for cooling and heating dampers, 1X on/off dry contact output to an aux. heater.
VAV Room Thermostat with Modbus interface Power supply: 24VAC/VDC	F2000LVC-A-N	1X 0~10V output for an actuator of VAV terminal with cool/heat manual switch. Modbus interface
	F2000LVC-A01	1X 0~10V output for an actuator of VAV terminal. 1Xon/off dry contact output to heater. Modbus interface
