Help CenterDeluxe Multistage Thermostat for AC System
Related Products
Specifications
7-day programmableup to 2 stages cooling and heating control
single speed fan control
large LCD
optional Remote contol
Deluxe Multistage Thermostat for AC System
Multistage Thermostat Features
u Deluxe design for control multistage AC systems with
a heat pump. It can control up to 2 stages cooling /2 stages heating with aux. a heater.
u Provides you a more comfortable and convenient living environment.
u Program a week 7 days up to four time periods and
temperature set points each day to complement your lifestyle and makes your room ambiance comfortable.
u Programs are permanently held in non-volatile
memory in the event of a power failure.
u Attractive turn-cover design, most frequently used keys are located on the face for quick and easy access to information. Program keys are located on the interior to eliminate accidental setting changes.
u Large LCD display with many messages for quick and easy readability and operation. Such as measurement and setting temperature, fan and
compressor work status, clock and program etc.
u Automatic compressor short cycle protection extends the life of the major equipment
u Auto or manual fan operation.
u Adjusted 1st and 2nd stage temperature differential
maintains optimal customer comfort.
u Auto or manual heat/cool changeover.
u Constant temperature allows continuous override
the program
u Temporary temperature override
u Temperature either °F or °C display
u Unique lockable function makes all keys locked to eliminate accidental operation.
u Low temperature protection
u Infrared remote control optional
u Backlight of LCD optional
u RS485 Communication interface optional
Specifications
Power supply |
24VAC±10% 50/60HZ |
Power consume |
≤ 1W |
Electrical rating |
1 amp maximum load per terminal |
Sensor |
NTC 5K @25°C |
Temperature degree |
Celsius or Fahrenheit |
|
Temperature control range (for heat/ cool) |
5~35°C (41~95°F) |
Accuracy |
±0.5°C (±1°F) @25°C |
Temperature differential |
Two temperature differentials setting for each cooling/heating stage |
Stages |
Up to 2 stages cooling/ 2 stages heating |
Programmability |
Program 7 days up to four time periods and temperature set points for each day |
Cool/heat Changeover |
Auto changeover or Manual switch selectable by end users |
Keys |
On the surface: power/ increase/ decrease key Inside: programming keys |
Net weight |
300g |
Dimensions |
110mm(L)×90mm(W)×25mm(H) |
Mounting standard |
Mounting on the wall, 2“×4“or 65mm×65mm box |
Housing |
PC/ABS plastic material with IP30 protection class |
Approval |
CE |
Model
MODEL |
DESCRIPTION |
F06NX -HP11-(F) |
For one stage heating/ one stage cooling with a heat pump, It also can be used as: F06NX-HC11 (one stage heating/ one stage cooling) F06NX-HC10 (one stage heating only) F06NX-HC01 (one stage cooling only) |
F06NXC-HP11-(F) |
F06NX -HP11 with RS485 communication interface. It’s also used as: |
F06NX-HP22-(F) |
For two stages heating/ two stages cooling with a heat pump. It also can be used as: F06NX-HC22 (two stages heating/ two stages cooling) F06NX-HC12 (one stage heating/two stages cooling) F06NX-HC21 (two stages heating/one stage cooling) |
OPTIONS | |
Backlight LCD -EL |
Blue backlight of LCD |
Remote Control-R |
Infrared remote control |
Shipping Information
Indiv. Ctn. Dim |
135mm×95mm×55mm |
Master Ctn. Qty |
40 |
Master Ctn. Dim |
44cm(L)X32cm(W)X32cm(H) |
Master Ctn. Wt. |
18KG |
