Specifications
thermostat for Fan Coil Unit of air conditioning systems7-day program of four time periods
RS485 communication interface
Power supply |
220VAC±10% / 110VAC±10% |
Power consume |
≤ 3W |
Electrical rating |
2 amp maximum load per terminal |
Sensor |
NTC 5K @25 |
Temperature degree |
Celsius or Fahrenheit |
|
Temperature control range (for heat/ cool) |
5~35 (41~95) |
Accuracy |
±0.5 (±1) @25 |
Programmability |
One week/7-day programmable and up to four time periods and temperatures pre-set for each day |
LCD Display |
91mm(L)X46mm(W) |
Buttons |
On the surface: power/ increase/ decrease Inside: for programming |
Housing |
PC/ABS plastic material with IP30 protection class |
Net weight |
370g |
Dimensions |
110mm(L)×90mm(W)×25mm(H) +28.5mm(back bulge) |
Mounting standard |
Mounting on the wall, 2×4or 65mm×65mm box |
1.Deluxe programmable thermostat for Fan Coil Unit of
air conditioning systems. Its designed to maintain your desired room temperature by 7-days program.
2.Many models for different FCU systems and also provide customized models.
3.Setting and operation easily by perfect buttons and large LCD. Provides you a more comfortable and convenient living environment.
4.Large LCD display with many messages for quick and easy checking and operation. Such as temperature measurement and set point, fan and valve working status, clock and program, etc.
5.Attractive turn-cover design, most frequently used keys are located right beside the LCD for
quick and easy operation. Program keys are located on the interior to eliminate accidental setting changes.
6.Programmable control for your convenience with 7-day program of four time periods and four temperatures each day.
7.All setup are kept on after the event of the power failure.
8.Auto or manual fan speed switch selectable.
9. °F or °C temperature display selectable.
10.Constant hold feature allows continuous override.
11.Temporary temperature override
12.Unique lockable function makes all keys locked to eliminate accidental operation.
13.Key-card option keeps on the save energy temperature in non-occupancy for hotels and returns back automatically to the pre-set temperature once occupancy.
14.Infrared remote control optional.
15.Blue backlight optional
16.RS485 communication interface optional
