Semiconductor CO Sensor With 6 LED Lights

Name: Semiconductor CO Sensor With 6 LED Lights
Brand: TONGDY
SKU: 141810128
Availability: InStock

Tongdy Sensing Technology Corporation (Beijing)

Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Beijing, China

Brand Name:

TONGDY

Model Number:

F2000TSM-CO-L

Payment & Shipping

Payment Methods:

Port of Shipment:

Beijing or Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Beijing, China

Brand Name TONGDY

Model Number F2000TSM-CO-L

Semiconductor CO Sensor with 6 LED lights

¨Features

u Wall mounting, real time detect CO level with measuring range of 0~500ppm.

u Japanese semiconductor CO gas sensor is inside with normal 5 years lifetime.

u Full time detects CO level, even the slightest leak can be detected

u One on/off output optional for control a fan or an alarm device.

u Convenient to select the CO range during four carbon monoxide ranges via a set of jumpers so that to control the relay output

u Special six indicator lights indicate six different CO level ranges.

u RS-485 communication interface optional with 15KV antistatic protection, independent address setting

¨Application

u Detect and indicate ambiance carbon monoxide level

u Used in both human and Industrial environment

u Kitchen rooms and restaurants

u Underground parking lots, maintenance garages

u Freezing machine rooms and other places where air quality is easy to worsen

u Automatic ventilation control

¨Specifications

Gas detected	Carbon monoxide
Sensing element	Semiconductor carbon monoxide gas sensor
Power Supply	24VAC/VDC
Consumption	2.5 W
Warm up time	36 hours (first time) 10 minutes (operational)
Response Time	<5 minutes for 90% step change
Signal Update	1s
CO Measuring Range	0~500ppm
Six indicator lights	The first green indicator light: CO≤0ppm The first and the second green indicator lights: CO ≥20ppm The first orange indicator light: CO≥50ppm The first and the second orange indicator lights: CO ≥100ppm The first red indicator light: CO≥200ppm The first and the second red indicator lights: CO≥300ppm
Relay output	One dry contact output, rated switching current 2A (resistant load)
Communication rate	Modbus RS485, 19200bps rate, 15KV antistatic protection
Operation temperature	0~60℃(32~140℉)
Operation humidity	5~95%RH, non condensing
Storage conditions	-10~60℃(14~140℉)
Net Weight	195g
Dimensions	100mm×80mm×28mm
Installation standard	65mm×65mm or 2”×4” junking box
Housing and IP class	PC/ABS fireproof plastic material, protection class: IP30
