Specifications
1.Indoor Carbon Monoxide Detector and Controller2. With 6 indicator lights.
3. Semiconductor gas sensor
2012 newest CO transmitter with semiconductor sensors
Gas detected | Carbon monoxide |
Sensing element | Semiconductor carbon monoxide gas sensor |
Power Supply | 24VAC/VDC |
Consumption | 2.5 W |
Warm up time | 36 hours (first time) 10 minutes (operational) |
Response Time | <5 minutes for 90% step change |
Signal Update | 1s |
CO Measuring Range | 0~500ppm |
Six indicator lights | The first green indicator light: CO≤0ppm The first and the second green indicator lights: CO ≥20ppm The first orange indicator light: CO≥50ppm The first and the second orange indicator lights: CO ≥100ppm The first red indicator light: CO≥200ppm The first and the second red indicator lights: CO≥300ppm |
Relay output | One dry contact output, rated switching current 2A (resistant load) |
Communication rate | RS485, 19200bps rate, 15KV antistatic protection |
Operation temperature | 0~60°C(32~140°F) |
Operation humidity | 5~95%RH, non condensing |
Storage conditions | -10~60°C(14~140°F) |
Net Weight | 195g |
Dimensions | 100mm×80mm×28mm |
Installation standard | 65mm×65mm or 2”×4” junking box |
Wiring terminals (max.) | 6 |
Housing and IP class | PC/ABS fireproof plastic material, protection class: IP30 |
1) Wall mounting, real time detect CO with measuring range of 0~500ppm.
2) With Japanese semiconductor CO gas sensor inside. More than 5 years lifetime.
3) Full time indicate CO level, even the slightest leak can be detected
4) Specially design with six indicator lights indicate six different CO level ranges.
5) One on/off output optional for control a fan or another device such as an alarm.
6) Different CO level corresponds with different light indicating. Four setting CO value ranges can be selected to control the relay output via a set of jumpers.
7) RS-485 communication interface optional with 15KV antistatic protection, independent address setting.
