China Waste Oil Distillation Equipment, Used Engine Oil to Base Oil Distillation Machine (Change black to yellow)
Features
1. Easy to operate, 1 ~ 2 workers can easily operate the machine.
2. Environmentally friendly in the whole operation, no smoke, no odor, without secondary pollution, the whole process is all sealed, won’t release any gas harmful to human and environment,
3. Series BOD System can recycle & distill various dirty black oils including waste engine oil, lube oil, gasoline oil, diesel oil, rubber oil, plastic oil, and other lubricant oil, and convert them to diesel oil and gasoline oil.
4. High quality and quantity of refined oil obtained through output, no any discoloration caused by oxidation, no any bad smelling/ odor.
5. Low operation cost only contains followings:
1) catalyst chemical, cost less than USD 30 to refine one ton of waste oil.
2) Heat energy consumption: 105 kcal per ton of waste oil
3) Power consumption: 40 KW to recycle 1 ton of waste oil
6. With High degree of automation in the whole operation, advanced designing and fabrication technology.
7. Adopt the water circulation method on atmospheric and vacuum distillation unit, very safe. And after decompression on the whole system, refined oil’s production quantity and quality are increased obviously.
8. The whole process is performed without acid and clay which are forbidden in many countries already.
9. High effective heating system: many heating sources can be used such as natural gas, furnace oil, coal, etc..
10. Low cost: only cost about USD30 of Pre-treatment reagent when treat 1 ton used oil. The Pre-treatment reagent is basic chemical material, can buy in every country, without any restrictions.
Technical Parameters
Item |
Model Unit |
DOD-3 |
DOD-5 |
DOD-10 |
DOD-15 |
DOD-30 |
|
Capacity |
Tons / day |
3 |
5 |
10 |
15 |
30 |
|
Recovery Rate |
% |
85 ~95 |
|||||
Working Pressure |
MPa |
≤0.4 |
|||||
Temperature Range |
℃ |
80 ~280 |
|||||
Working noise |
dB(A) |
≤85 |
|||||
Power supply |
380V/ 3 Phase/ 50Hz (or as per your needed) |
||||||
Electrical Power |
kW |
18 |
20 |
24 |
28 |
30 |
|
Cooling Method |
Water Circulation Cooling |
||||||
Heating Energy Source |
By Natural gas, finance oil, coal, etc… |
||||||
Weight |
Tons |
6 |
8.5 |
16 |
29 |
37 |
|
Manufacture Time |
Days |
25 |
30 |
35 |
35 |
45 |
|
Performance Characteristics,Advantage Introduction
1. Low cost: only cost about USD30 of Pretreatment reagent when treat 1 ton used oil. The Pretreatment reagent is basic chemical material, can buy in every country, without any restrictions.
2. Easy operation: 1~2 people can easily operate the machine
3. environmental protection: the whole process is all sealed, won’t release any gas harmful to human and environment, the colloid and asphalting, carbon black in the waste lube oil are all into sludge, can be used as asphalt or fuel.
4. widely usage: can treat gasoline engine oil, diesel oil, rubber oil and other waste lube oil of the engine, also a variety of cleaning oil.
5. high recovery rate: Base oil:85%~88% gasoline3%.diesel:3-4% sludge:6%~8%.
6. Do not need acid and clay, get high quality base oil : No unsaturated composition, can storage in a long-term without change its color, also no any bad smell.
7. This is the most advanced technology in the world and suitable for large-scale industrial production.
China Waste Oil Distillation Equipment, Used Engine Oil to Diesel Distillation Machine (Change black to yellow)
If This not your needing type, follow is our catalogue for your to choose:
Series ZY Single-Stage Vacuum Transformer Oil Purifier
Series ZYD Double High Vacuum Transformer Oil Purifier(Application Large Power Equipments Of Above 110KV especially for those over 500 Meters Height Area).
Series ZYB Multiply-Function Insulating Oil Treatment Machine
Series TY Turbine Oil Purification Apparatus
Series TYA Lubricating Oil/Hydraulic Oil Purification unit(Apply to Degassing)
Series TYA-C Luricating Oil Purification Machine(Apply to Decolorization)
Series BOD Black Dirty Oil Regeneraion Equipment
Series DOD Waste Oil Distillation System
Series TYB Portable Light Fuel oil Purification Machine
Series LY Plate Pressure Oil Purifier
Series TYD Vacuum Dehydrator
Series JL Portable Oil Filtering and Oiling Machine
Series IIJ Oil Tester(BDV Tester)
Standard wooden case package of export, it is suitable for long distance sea shipping and train transportation, and we will check carefully per packing process before shipment.
Used essential oil distillation equipment, engine oil recycling machine
Since the foundation of our company, we have been devoting our efforts to developing better purifiers for energy saving. With the intellectual support form our first-rate oil purification experts and encouraged by the company's modern management mechanism, we have developed six series of products, including hundreds of oil purifier models with independent intellectual property and advanced purification technology. Our equipment can be applied to many fields, such as electric power, petroleum chemical, metallurgical industry, mining, aviation, shipping railway and so on.
We adhere to the tenet of mutual-benefit and win-win business. With the sincere and pragmatic work attitude, we would like to open up a new oil purification are with our customers.
We are offering practical and functional products with competitive Price!!
If you have any question, Please Contact with us directly!!
Contact: Ansen Zuo
Mob: +86 136 6808 0522(whatsapp)
Tel: +86-23 6868 1157
Fax: +86-23 6806 0921
Wechat:ansenzuo
E: oilpurifier.ansen(at)
