Highly Sensitive Hot Selling Soil Moisture Meter, Good Price 4 20 Ma/RS485 Output Soil Moisture Sensor For Agriculture

Highly Sensitive Hot Selling Soil Moisture Meter, Good Price 4 20 Ma/RS485 Output Soil Moisture Sensor For Agriculture photo-1
Highly Sensitive Hot Selling Soil Moisture Meter, Good Price 4 20 Ma/RS485 Output Soil Moisture Sensor For Agriculture photo-2
Highly Sensitive Hot Selling Soil Moisture Meter, Good Price 4 20 Ma/RS485 Output Soil Moisture Sensor For Agriculture photo-3
Highly Sensitive Hot Selling Soil Moisture Meter, Good Price 4 20 Ma/RS485 Output Soil Moisture Sensor For Agriculture photo-4
Highly Sensitive Hot Selling Soil Moisture Meter, Good Price 4 20 Ma/RS485 Output Soil Moisture Sensor For Agriculture photo-5
Highly Sensitive Hot Selling Soil Moisture Meter, Good Price 4 20 Ma/RS485 Output Soil Moisture Sensor For Agriculture photo-6
US$ 110 - 125 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Anying
Model Number:
A-SM1
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name Anying
Model Number A-SM1

Highly Sensitive newest soil moisture meter

4 20 ma/RS485 Output Soil Moisture Sensor

Related Products

"Quality is Our Culture!"

Click the picture or the title to know more details.

Highly Sensitive Hot Selling Soil Moisture Meter, Good Price 4 20 ma/RS485 Output Soil Moisture Sensor For AgricultureHighly Sensitive Hot Selling Soil Moisture Meter, Good Price 4 20 ma/RS485 Output Soil Moisture Sensor For AgricultureHighly Sensitive Hot Selling Soil Moisture Meter, Good Price 4 20 ma/RS485 Output Soil Moisture Sensor For Agriculture
Anying Temperature & Humidity Sensor TH6

Unique design, easy to install

Relay & RS485 Output

with external sensor

Enable Software Management

Anying Humidity & Temperature Controller TH1

Clear LCD screen to show real-time data

RS485 Output

with built-in sensor

Enable Software Management

Anying CO2 Sensor SM3370M



High sensitive infrared sensor probe
Self-diagnosis function
Convenient installation and maintenance
Optional: 4~20mA , 0~5V , 0~10V or RS485 output
Highly Sensitive Hot Selling Soil Moisture Meter, Good Price 4 20 ma/RS485 Output Soil Moisture Sensor For AgricultureHighly Sensitive Hot Selling Soil Moisture Meter, Good Price 4 20 ma/RS485 Output Soil Moisture Sensor For AgricultureHighly Sensitive Hot Selling Soil Moisture Meter, Good Price 4 20 ma/RS485 Output Soil Moisture Sensor For Agriculture
Anying Lux Meter A-LUX1



Waterproof, easy installations
Stable remote control
3 optional output: 0-5V/4-20mA/RS485/RS232
3 optional power supply: 220V AC/24V AC/24V DC
Anying Conductivity Sensor A-EC01

High sensitivity and stability
3 Options of Output signals:
Voltage output:0~5V or 0~2V
Current output:4-20mA
Digital output:RS485





Anying PH Sensor A-PH01

Standard & friendly English interface
Equipted with relays
Together with temperature sensor
3 optional output: 0-5V/4-20mA/RS485
3 optional power supply: 220V AC/24V AC/24V DC





Product Feature



MS10 is a high-sensitivity and precise sensor to detect the real time moisture and temperature. By measuring the permittivity of soil, could directly and stably show the moisture. MS10 adopt International Standard measuring method to measure the water content of soil. It can be used in Scientific Experiment, Water-Saving Irrigation, Greenhouse, Flower & Vegetable Growing, Grass & Farm, Soil Quick Testing, Planting, Sewage Treatment, Grain Storage, Precise Agriculture etc., and it has been applied to Water Conservancy, Meteorology, and moisture of some particulate matter.

  • High sensitivity and accuracy, good interchangeability, could be used in all kinds of soil.
  • Reliably sealing, corrosion resisting, long serving life in the soil
  • With flame-retardant epoxy resins to make sure strong waterproof and anti-impact ability.
  • Probe is made of high quality steel, the sensor can endure long time electrolysis and the corrosion of acid & base in the soil.
  • Protected from inverse wire connection.
Details Show



Technical parameter

(Three Outputs, Free to Choose)

Signal output

Voltage output 0-2V

Output resistance <1Kohm

Current output 4-20mA

<500ohm

RS485 Communication, Mod bus Protocol

Supply voltage

5-24V/DC

12-24V/DC

5-24V/DC

Max Power consumption

40mA@24V DC

80mA@24V DC

(when both of the current output are 20mA)

30mA@24V DC

Detected area

In the 7cm high, 7cm diameter cylinder with the central pin as the center

Response time (water content and temperature)

Less than 1s

Soil moisture measuring range

choice:

0-30%

0-50%

0-100%

Soil moisture accuracy

0-53%: ±3%;

53-100%: ±5%

Soil temperature measuring range

-40~80℃

Soil temperature accuracy

±0.5℃

Waterproof

IP68

Working environment

-40~85℃

Storage environment

-40~85℃

Material of probe

Food-grade steel

Sealing material

Black flame-retardant epoxy resins

Installation way

Complete buried or pins buried in the detected medium



We offer the free bundled software of this sensor (WIN version), and we could provide the protocol.



Highly Sensitive Hot Selling Soil Moisture Meter, Good Price 4 20 ma/RS485 Output Soil Moisture Sensor For Agriculture

Highly Sensitive Hot Selling Soil Moisture Meter, Good Price 4 20 ma/RS485 Output Soil Moisture Sensor For Agriculture

Highly Sensitive Hot Selling Soil Moisture Meter, Good Price 4 20 ma/RS485 Output Soil Moisture Sensor For Agriculture

Highly Sensitive Hot Selling Soil Moisture Meter, Good Price 4 20 ma/RS485 Output Soil Moisture Sensor For Agriculture

Shipping & Payment

Highly Sensitive Hot Selling Soil Moisture Meter, Good Price 4 20 ma/RS485 Output Soil Moisture Sensor For Agriculture

About ANYING

Highly Sensitive Hot Selling Soil Moisture Meter, Good Price 4 20 ma/RS485 Output Soil Moisture Sensor For Agriculture

Our Service

Highly Sensitive Hot Selling Soil Moisture Meter, Good Price 4 20 ma/RS485 Output Soil Moisture Sensor For Agriculture

The OEM service is offered if needed.
