Promotion portable Greenhouse using
digital soil moisture meter, soil ph
moisture meter, soil moisture sensor
Item : Soil Moisture (Temperature)Sensor Instruction
Technical parameter
Technical parameter | |||
Signal output |
Voltage output 0-2V Output resistance <1Kohm |
Current output 4-20mA <500ohm |
RS485 Communication,Mod bus Protocol |
Supply voltage |
5-24V/DC |
12-24V/DC |
5-24V/DC |
Max Power consumption |
40mA@24V DC |
80mA@24V DC (when both of the current output are 20mA) |
30mA@24V DC |
Detected area |
In the 7cm high, 7cm diameter cylinder with the central pin as the center |
||
Response time(water content and temperature) |
Less than 1s |
||
Soil moisture measuring span |
choice: 0-30% 0-50% 0-100% |
||
Soil moisture accuracy |
0-53%:±3%; 53-100%:±5% |
||
Soil temperature measuring span |
-40~80℃ |
||
Soil temperature accuracy |
±0.5℃ |
||
Waterproof |
IP68 |
||
Working environment |
-40~85℃ |
||
Storage environment |
-40~85℃ |
||
Material of Spin |
Food grade steel |
||
Sealing material |
Black flame-retardant epoxy resins |
||
Installation way |
Complete buried or pins buried in the detected medium |
||
features
♦High sensitivity and accuracy, good interchangeability.
♦Reliable sealing, corrosion resisting, long service life in the soil
♦With flame-retardant epoxy resins , make sure strong waterproof and anti-impact of external forces
♦Made of high quality steel, the sensor can endure long time electrolysis and the corrosion of acid & base
in the soil
♦Protected from inverse wire connection
