Multi Wire Drawing Machine
USD $10,000 - $90,000
/ Set
1 Set(Min.Order)
- Tianjin
- T/T Credit Card
You May Like
-
Wire drawing die polishing machine
-
Hot ! Australia High Standard Galvanized Temporary Fence For Children
-
3 inch speaker grille with CE RoHS
-
Perforated metal aluminum mesh speaker grille/perforated metal mesh speaker grille(Factory)
-
1.5mm Thickness Perforated Metal Mesh Speaker Grille
-
304 20 10 meshes stainless steel speaker grill wire mesh(hebei anping factory)
Product Details
| Condition | New | Inlet Diameter | 6.5mm | |
| Outlet Diameter | 1.7mm | Place of Origin | Hebei, China | |
| Brand Name | HONGYE | Model Number | HY-S-281, HY-S-281 | |
| Voltage | 380v | Power(W) | 37000 | |
| Dimension(L*W*H) | 13000*1200*1500 | Weight | 25 tons | |
| Certification | CE/ SGS | Warranty | 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1no pollution2.drawing wire steady and uniform
3.nice shape and easy operation
4. 12 years experience
Product Description
Features:
- High speed and stable running
- Easy operation, AC frequency control
- Air cooling + Water cooling
- Vacuum system-Clean the dust, protect environment
- Capstan: Unique overlay welding technology, can use over 2000 hours
- Remote control: Find and solve electrical problems
Application:
It is applied for the production of prestressing strand, steel cord, bead wire, steel wire, spring steel wire, stainless steel wire, gas welding wire, arc welding wire,etc.
Specification:
| Items | Unit | LZ9-12/1200 | LZ10/800 | LZ9/700 | LZ10/560 | LZ10/400 |
| Reel diameter | mm | 900 | 800 | 700 | 560 | 400 |
| Draw passage | time | 9-12 | 10 | 9 | 10 | 10 |
| Incoming dia | mm | Φ14-8 | Φ10-8 | Φ8-6.5 | Φ6.5-5.5 | Φ14-8 |
| Outgoing dia | mm | Φ5-3 | Φ4-3 | Φ3-2.5 | Φ2-1.8 | Φ1-0.8 |
| Wire darwing line | m/min | 300 | 360 | 480 | 720 | 840 |
| Incoming strength | Mpa | ≤1300 | ≤1300 | ≤1300 | ≤1300 | ≤1300 |
| Total compressibility | % | 87.24-85.94 | 84-85.94 | 85.94-85.21 | 90.53-89.29 | 87.24-84 |
| Average compressibility | % | 20.48-19.58 | 18.42-19.58 | 19.58-19.13 | 21.00-20.02 | 18.61-16.74 |
| Single motor power | Kw | 110-90 | 90-55 | 75-55 | 37-22 | 15-7.5 |
Note: We can design the machine according to customers' requirements.
