Made in China Cattle Fence/wrought Iron Metal Sty (AnPing Wire Mesh Base)

Name: Made in China Cattle Fence/wrought Iron Metal Sty (AnPing Wire Mesh Base)
Brand: HONGYE
SKU: 141803530
Availability: InStock

US$ 15.5 - 68.5 MOQ: 100 Pieces

Key Specifications

Place of Origin:

Hebei, China

Brand Name:

HONGYE

Model Number:

HY-S-291, HY-S-291

Beijing Hongye Metal Products Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hebei, China

Brand Name HONGYE

Model Number HY-S-291, HY-S-291

Material Other, Galvanized Iron Wire, Galvanized Iron Wire

Type Welded Mesh

Application Fence Mesh

Hole Shape Square

Aperture weft: 150mm, warp: adjustable

Wire Gauge 1.8-2.5mm(, inner wire ), 1.8-3.5mm

Specifications

Cattle rail fence
1.Pretty design,good quality
2.Colorful choice
4.Long life time
5.Portable, easy handle

Product Description

Specification :

Num		Specification mesh			Gross Weight (kg)		Set and bottom silk Diameter (mm)		In silk Diameter (mm)		Volume diameter (mm)
	Type		Specification
1	7/150/813/50		102+114+127+140+152+178	19.3		2.5		2.0		270
2	8/150/813/50		89(75)+89+102+114+127+140+152	20.8		2.5		2.0		270
3	8/150/902/50		89+102+114+127+140+152+178	21.6		2.5		2.0		270
4	8/150/1016/50		102+114+127+140+152+178+203	22.6		2.5		2.0		270
5	8/150/1143/50		114+127+140+152+178+203+229	23.6		2.5		2.0		270
6	9/150/991/50		89(75)+89+102+114+127+140+152+178	23.9		2.5		2.0		270
7	9/150/1245/50		102+114+127+140+152+178+203+229	26.0		2.5		2.0		270
8	10/150/1194/50		89(75)+89+102+114+127+140+152+178+203	27.3		2.5		2.0		270
9	10/150/1334/50		89+102+114+127+140+152+178+203+229	28.4		2.5		2.0		270
10	11/150/1422/50		89(75)+89+102+114+127+140+152+178+203+229	30.8		2.5		2.0		270
For example , 7/150/813/50 ------ “7” means the horizontal wire quantity , “150” means the vertical wire spacing (mm), “813” means the width of the wire mesh (mm), “50” means the length of each roll (m) ,the length can be made according to your requirement .
