Specifications
gabion box prices/gabion wall construction:Factory Price (competetive
Material:Galvanized Steel Wire
Technique:Woven
Cer
1.Description
Gabion baskets are available in a variety of different sizes. They come in 1/2 or 1 meter high, and 2, 3, or 4 meters long. There are several types and colors of rock available from common river type round rock, to multi-colored light and dark fractured rock.
1. Gabion basket /gabion mattress is made of steel mesh with the type 6*8mesh.
2. The diameter of the wire mesh has normally two types: 2.7/3.7mm or 2.0/3.0 mm.
3. The gabion element is in the shape of block or regular cube size. These special wire bins are made of robust wire, filled with the vibrations at the quarry and transport are accompanied by the lifting straps.
4. The wire of the outside frame edge is one wire gauge thicker than the wire used for hexagonal wire netting.
5. Wires of gabion basket can be classified into mesh wire, selvedge wire and tie wire. The selvedge wire is thicker than the other two wires.
|
Opening (mm) |
Wire Diameter (mm) |
Wire Diameter(PVC Coated) Inner/outside(mm) |
Strands |
| 60x80 | 2.0-2.8 | 2.0/3.0-2.5/3.5 | 3 |
| 80x100 | 2.0-3.2 | 2.0/3.0-2.8/3.8 | 3 |
| 80x120 | 2.0-3.2 | 2.0/3.0-2.8/3.8 | 3 |
| 100x120 | 2.0-3.4 | 2.0/3.0-2.8/3.8 | 3 |
| 100x150 | 2.0-3.4 | 2.0/3.0-2.8/3.8 | 3 |
| 120x150 | 2.0-4.0 | 2.0/3.0-3.0/4.0 | 3 |
Mesh sizes |
Numberof Diaphragm |
Approximate Dimensions and Volumes |
Tolerance |
Colour |
Wire diameter (mm) |
|||
length |
width |
depth |
capacity |
|||||
|
60X80
80X100
80X120
100X120 |
2 |
3.0 |
2 |
0.17 |
0.90 |
length±5%
width±5%
depth±5%
|
Blue Red Yellow Green White Balck Grey |
Heavily galvanized or galfan coated wire 2.00, 2.20, 2.40, 2.70,3.00 Or PVC coated on Heavily Galvanised or Galfan coated wire 2.0/3.0, 2.2/3.2, 2.4/3.4, 2.7/3.7, 2.0/4.0 |
2 |
3.0 |
2 |
0.23 |
1.25 |
||||
2 |
3.0 |
2 |
0.30 |
1.80 |
||||
3 |
4.0 |
2 |
0.17 |
1.20 |
||||
3 |
4.0 |
2 |
0.23 |
1.80 |
||||
3 |
4.0 |
2 |
0.30 |
2.40 |
||||
4 |
5.0 |
2 |
0.17 |
1.50 |
||||
4 |
5.0 |
2 |
0.23 |
2.25 |
||||
4 |
5.0 |
2 |
0.30 |
3.00 |
||||
(All can be customized)
2.Material:Low Carbon Steel Wire, Stainless Steel Wire.
3.Surface Treatment:Hot Dip Galvanized, Galfan, PVC coated.
4.The Gabion basket Assembly :
1)First of all construction workers will each piece upright , to ensure that the tablets in an accurate position .
2)Gabion lashing the four comes of points can be used to tie banding ligation wire or metal buckle .
3)With binding wire or metal buckle to connect with each piece and body .
