NIR emitter halgoen infrared lamp for silver ink sintering
- 10000 Piece / Pieces per Month
- shanghai
- T/T Credit Card
You May Like
-
Screen printing use Halogen Infrared emitter lamp 1200W
-
Screen printing use Shortwave Infrared emitter lamp 2000W
-
Screen printing use Shortwave IR heating emitter 1800W
-
Shortwave double tube infrared lamp heater
-
Fast medium wave quartz infrared emitter for drying
-
Quartz infrared heating shortwave IR emitter
Product Details
| Place of Origin | Anhui, China | Brand Name | Quickly | |
| Color | Other, transparent, Yellow, white coated | Specification | Other | |
| Material | Other, quartz, Quartz, high-calss imported quartz sand and heating filament | Certification | Other, CE, CE, CE approved by EMC |
Product Description
Product | Short wave IR heat lamp | Medium wave IR heat amp | |
Wave length | 1.0-1.4μm | 2.4-2.7μm | |
Heating response time | 1 second | 1-4min | |
Voltage | 110v/230v/380v/400v,customized available | ||
Max. Length for twin tube | 6000mm | ||
Max. filament temp | 2200°C | 900°C | |
Watt density | 35-200w/cm | 10-30w/cm | |
Working expectation | 5000hours | 20000hours | |
Dia. of twin tube | 23×11mm / 33×15mm | ||
Wall thickness of tube | 0.8mm,1.0mm,1.2mm,1.5mm,1.8mm | ||
Dia. of single tube | Φ10mm, Φ11mm, Φ12mm, 15mm,18mm, 20mm | ||
Max. length for single tube | 1600mm(Φ12mm) | 2000mm(Φ15mm) | |
Main material | filament | tungsten filament | Ni80Cr20 heating wire |
| quartz glass | can resist high temperature, sudden hot and cold | |
Inner structure of quartz tube | Quartz envelope profile , vacuum processing with protective halogen gas inflation, which provide a safe working environment | Quartz envelope profile , Non-vacuum | |
Surface of quartz tube | 1. White reflector/Gold reflector: High heat radiation rate 2. Transparent tube: Normal style 3. Ruby tube for shortwave |
