Infrared heating lamp
Infrared heating is a kind of radiation heating. It spreads by a kind of infrared radiation (light)-- infrared light from material in the form of molecular (atomic) resonance absorption, so as to achieve the purpose of heating. It can be applied in many fields such as the heating process of industry coating, plastic forming, automotive industry, glass making, spinning, solar PV, food baking, drying of printing inks, quick drying of primer and paint on furniture, printed circuit, and so forth.
Product Catalog links as follow:
- Shortwave heat lamp
- Medium Wave heat lamp
- Carbon fiber far infrared heat lamp
- Fast Medium wave heat lamp
- Infrared heater panel
Specifications:
- · Infrared quartz tube
- Lifespan: 5000 hours
- Certification: CE
- Suitable for new type quartz tube heaters
- Voltages: 110, 220 or 380V or other voltage grades needed by users
- Power: 0.3 to 6kW
- Length: 300 to 3000mm
- Outer diameter: 10-18mm, 23-33mm
- Surface temperature of heater divides into three grades:
- o Low temperature: 400 to 600℃
- o Mid temperature: 600 to 800℃
- o High temperature: 800 to 1000℃
- Wavelength:1.0-1.4um
- The Max unit area:200kw/sqm
- Reaction time:1S
Advantages:
- Process, design and products can be customized
- · 5000 hours lifespan
- · CE certification
- · Small order accepted
- · Science,energy saving,safety and environmental protection
- · Single-ended wire
- · Very short time of heating and cooling
- · Reasonable price
Application
Technology Overview Especially in plastics processing thermoplastics, heating plays a key role. Soften plastics, molding and other processes such as bending, stretching, blown, cotton and so on need to be heated; application on the packaging material, heat can be used for aseptic processing, shrink packaging, sealing and composite. Likewise, the plastic tempering, hardening, gluing or heat drying is also inseparable. Heating was even used to separate plastic waste.
Infrared radiation, heating as an important way for a variety of heating needs of the plastics industry offers a viable solution.
Packing ways: wooden packing
Delivery Time: 10-15 days after receiving the deposit
Hefei Quickly Electric Co., Ltd is a company full of power and thought. With decades of studying on the infrared radiation, we find that heating by infrared light can help us improve the efficiency of producing and save a lot of energy we used to losing. It directly produce a same wavelength as the heated objects so as to ensure the mass use of energy. It breaks the tranditional heating ways and quickly used in every heating process these years. It has been a trend of using it to replace the original heating ways!
