Help Center2015 New Product Infrared Heat Lamp for Powder Coating Oven
Related Products
-
Quartz Infrared Heating Element for Powder Coat CuringUS$ 1 - 200MOQ: 100 Meters -
Quratz Infrared Heating Element Tube for Powder Coating Oven PartsUS$ 1 - 200MOQ: 300 Meters
-
Infrared Heating Element ir Lamp Quartz Tube for Powder Coating OvenUS$ 1 - 200MOQ: 100 Pieces
-
Quartz Halogen Infrared Heating Element for Powder Coat CuringUS$ 1 - 200MOQ: 100 Meters
-
Infrared Quartz Heating Tube for Powder CoatingUS$ 1 - 200MOQ: 100 Meters
Infrared heating lamp
Product Catalog links as follow:
- Shortwave heat lamp
- Medium Wave heat lamp
- Carbon fiber far infrared heat lamp
- Fast Medium wave heat lamp
- Infrared heater panel
Technical Parameters of infrared heat lamps
Short wave
Voltage |
100, 110, 120, 220, 230, 240 V |
Wattage |
300 -6000W |
Dia |
10,12,15,20,8*18,23*11,33*15mm |
Electricity saving rate |
30% |
Wavelength |
1.0-1.4um |
Response Time |
1s |
Electric heat transformation rate |
>98% |
Temperature(surface) |
2200℃ |
Max heating length |
6400/ 2400 mm |
Wire temperature |
1800 ° - 2400 °C
|
Max power per unit area |
200 kW /m2 |
|
|
IR Benefits and Features of infrared heat lamps
Long life |
More than 5000h |
Instant heat |
within 1 second reaction time |
High power density |
up to 200w/cm |
High control ability |
neither ballast nor special circuits are necessary for basic usage |
No air droughts |
because of radiation |
Clean |
No byproducts, no pollution |
Extensive assortment |
voltage,wattage,length,base,cables and other specifications are available |
High efficiency |
more than 85% heat efficiency of full power. |
|
Economical
|
More than 85% of consumed energy transmitted into infrared heat |
Heat can be focused |
Same optical properties as light,can be directed by reflectors |
Safe |
Quartz envelope, heat shock resistant |
Product showcase:
Application
Infrared heating lamp application | |
Automotive |
Primer coat,Color coat,Clear coat,Powder coat, Seat de-wrinkling,Head liner forming |
Plastics |
Welding,Forming,Softening,Curing,Drying |
Printing |
Ink drying,Silk Screening,Bindings,Glue drying |
Food |
Baking,cooking,stove,Browning,Dehydrating,Pasteurizing |
Electronics |
Re-flow soldering,Water dry-off,Silk screening |
Textiles |
Web Drying,Finishing,Pre-shrinking |
Glass- Ceramics |
Heating safety glass,Drying mirrors,Drying frit |
Farm |
Space heating,Incubating,Brooders |
Infrared heat lamps
HOMEPAGE OF ALIBABA
FAQ
1.Can you make custom size lamp?
All of our infraredlamps are customized,the size,voltage and wattage,reflector and etc.
Just tell me what you need,or send us drawing.We will give you the lamp you want.
2.what is the warranty?
Short wave infrared lamp lifespan 5000 hours,Medium wave infrared lamp lifespan 20000 hours,carbon fiber lamp lifespan 10000 hours,fast medium wave lamp lifespan 10000 hours(man-made and improper operation excluded) infrared heat lamps
3.How about the after Sales?
Every infrared lamp will tested by our QC department before shipping.If the infrared heat lamps have damage in transit or the life time less than we guaranteed(man-made excluded}.We will send you new infrared heat lamps for replacement. (infrared heat lamps)
4.What is the payment term?
We accept T/T,Paypal,Western Union,L/C(infrared heat lamps)
5.How about the delivery time?
10-15 working day after receiving the deposit for the infrared heat lamps
6.How about the package?
Outside packed in wood and inside packed in soft EPE soft foam mat, we can do package according to your design. (Infrared heat lamps)
