Halogen Infrared Heating Element 110V for Powder Coat Curing
US$ 1 - 200
MOQ: 100 Meters
Key Specifications
Get Latest Price
Place of Origin:
Anhui, China
Brand Name:
KKL
Type:
Clear Quartz Pipe, transparent short-wave Infrared heating lamp
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Temperature Quartz Tube for Powder Coat Curing With CE Certificate,20000 HoursUS$ 1 - 200MOQ: 300 Pieces -
Quartz Halogen Infrared Tube for Powder Coat Curing,20000 Hours LifespanUS$ 1 - 200MOQ: 300 Pieces
-
High Temperature Quartz Tube for Powder Coat CuringUS$ 1 - 200MOQ: 300 Pieces
-
Quickly Powder Coating Curing Heat ElementUS$ 1 - 200MOQ: 300 Pieces
-
Gold Reflector Single Tube Quartz Heat Lamp for Paint & Powder FinishingUS$ 1 - 100MOQ: 300 Pieces
Place of Origin
Anhui, China
Brand Name
KKL
Color
transparetn, transparent
Application
heating and drying process, widely used in all kinds of industry heating process
Outside Diameter
10,12,23*11,33*15mm
Infrared lamp
Infrared heating is a kind of radiation heating. It spreads by a kind of infrared radiation
(light)-- infrared light from material in the form of molecular (atomic) resonance absorption,
so as to achieve the purpose of heating. It can be applied in many fields such as the
heating process of industry coating, plastic forming, automotive industry, glass making,
spinning, solar PV, food baking, drying of printing inks, quick drying of primer and paint
on furniture, printed circuit, and so forth.
Specifications:
- · Infrared quartz tube
- Lifespan: 5000 hours
- Certification: CE
- Suitable for new type quartz tube heaters
- Voltages: 110, 220 or 380V or other voltage grades needed by users
- Power: 0.3 to 6kW
- Length: 300 to 3000mm
- Outer diameter: 23-33mm
- Surface temperature of heater divides into three grades:
- o Low temperature: 400 to 600℃
- o Mid temperature: 600 to 800℃
- o High temperature: 800 to 1000℃
- Wavelength:1.0-1.4um
- Reaction time:1S
Advantages:
- Process, design and products can be customized
- · 5000 hours lifespan
- · CE certification
- · Small order accepted
- · Science,energy saving,safety and environmental protection
- · Single-ended wire
- · Very short time of heating and cooling
- · Reasonable price
