Infrared heating
Practice has approved infrared heating superior to traditional heating such as hot air,steam,ceramic,gas,or
metal radiator.
Infrared heating features: large amounts of energy can be released quickly and accurately,and match the
producing process and production perfectly to heat the objects,infrared heating need no conversion
of intermedium,infrared heating with different wave length can precisely match the heated
material's wave length,get the purpose of heating and drying in
a shorter time,with high quality.Long warranty of heating lamps,reduce the cost ,with no by-
product and pollution,realize green economy,and sustainable development.
Technical Parameters
Voltage | 100, 110, 120, 220, 230, 240 V |
Wattage | 300 -6000W |
Dia | 10,12,15,20,8*18,23*11,33*15mm |
Electricity saving rate | 30% |
Wavelength | 2.0 µm |
Response Time | 1 - 4 min |
Electric heat transformation rate | >98% |
Temperature(surface) | 1200℃ |
Max heating length | 1500/ 2000/ 6500 mm |
Wire temperature | 1200 °C |
Max power per unit area | 60 kW /m2 |
IR Benefits and Features
Long life | More than 20000h |
Instant heat | within 1-4 min reaction time |
High power density | up to 25w/cm |
High control ability | neither ballast nor special circuits are necessary for basic usage |
No air droughts | because of radiation |
Clean | No byproducts, no pollution |
Extensive assortment | voltage,wattage,length,base,cables and other specifications are available |
High efficiency | more than 85% heat efficiency of full power. |
Economical
| More than 85% of consumed energy transmitted into infrared heat |
Heat can be focused | Same optical properties as light,can be directed by reflectors |
Safe | Quartz envelope, heat shock resistant |
| Infrared heating lamp application | ||||||
| Automotive | Primer coat,Color coat,Clear coat,Powder coat, seat de-wrinkling,Head liner forming | |||||
| Plastics | Welding,Forming,Softening,Curing,Drying | |||||
| Printing | Ink drying,Silk Screening,Bindings,Glue drying | |||||
| Food | Baking,cooking,stove,Browning,Dehydrating,Pasteurizing | |||||
| Electronics | Re-flow soldering,Water dry-off,Silk screening | |||||
| Textiles | Web Drying,Finishing,Pre-shrinking | |||||
| Glass- Ceramics | Heating safety glass,Drying mirrors,Drying frit | |||||
| Farm | Space heating,Incubating,Brooders | |||||
1.Can you make custom size lamp?
All of our lamps are customized,the size,voltage and wattage,reflector and etc.Just tell me what you
need,or send us drawing.We will give you the lamp you want.
2.what is the warranty?
Short wave infrared lamp lifespan 5000 hours,Medium wave infrared lamp lifespan 20000 hours,carbon fiber lamp lifespan 10000 hours,fast medium wave lamp lifespan 10000 hours(man-made and improper operation excluded)
3.How about the after Sales?
Every lamp will tested by our QC department before shipping.If the lamps have damage in transit or the life time less than we guaranteed(man-made excluded}.We will send you new lamps for replace.
4.What is the payment term?
We accept T/T,Paypal,Western Union,L/C
5.How about the delivery time?
10-15 working day after receiving the deposit
6.How about the package?
Outside packed in wood and inside packed in soft EPE soft foam mat, we can do package according to your design.
7.How to contact Quickly?
Skype: cathy520zjf
QQ:2764732842
Mobile: 86-13767487075
Phone:86-551-65208999-604
WhatsApp: 13757487075
