Home > Products > medium-wave heating lamp > electric heater parts,,supplied to industrial heating equipment,energy saving,20000 hours,can be customized
electric heater parts,,supplied to industrial heating equipment,energy saving,20000 hours,can be customized
- 10000 Piece / Pieces per Month
- Shanghai
- T/T
- Heater Core Heater Welding Gun Heater Element
- Industrial Diesel Heater /Agricultural Vegetable Planting/Aquaculture Industry Heater
- Preheating equipment for hardbandig welding
- Heater Core Heater Welding Gun Heater Element
- DL-3 model electric air heater with upper outlet and lower inlet
- DL-2 model electric air heater with Left-Right Circulation
Product Details
Condition: | New | Type: | Other, Infrared Heater, Infrared heating lamp | Power Source: | Electric |
Brand Name: | Quickly | Model Number: | KKLG-ZB-T003 | Dimension(L*W*H): | 33*15mm |
Voltage: | 380v, 110V, 220V, 240V, 380V, customized. | Power(W): | 4kw | Certification: | CE, CE approved by EMC |
Warranty: | 20000 hours | After-sales Service Provided: | No overseas service provided |
Product Description
Infrared heating lamp
Infrared heating is a kind of radiation heating. It spreads by a kind of infrared radiation (light)-- infrared light from material in the form of molecular (atomic) resonance absorption, so as to achieve the purpose of heating. It can be applied in many fields such as the heating process of industry coating, plastic forming, automotive industry, glass making, spinning, solar PV, food baking, drying of printing inks, quick drying of primer and paint on furniture, printed circuit, and so forth.
Specifications:
- Gold-coated or infrared quartz
- With gold reflective side, can save more than 50% energy
- Lifespan: 20000 hours
- Certification: CE
- Suitable for new type quartz tube heaters
- Voltages: 110, 220 or 380V or other voltage grades needed by users
- Power: 0.3 to 6kW
- Length: 300 to 3000mm
- Outer diameter: 23-33mm
- · Surface temperature of heater divides into three grades:
- o Low temperature: 400 to 600℃
- o Mid temperature: 600 to 800℃
- o High temperature: 800 to 1000℃
- Wavelength:>1.4um
- The Max unit area:150kw/sqm
- Reaction time:1-2S
Advantages:
- Process, design and products can be customized
- · 20000 hours lifespan
- · CE certification
- · Small order accepted
- · Science,energy saving,safety and environmental protection
- · Single-ended wire
- · Very short time of heating and cooling
- · Reasonable price
Packing ways: wooden packing
Delivery Time: 10-15 days after receiving the deposit
We have a specialized design team and efficient service department, welcome your any technical question and kind inquiry. We are pleasure to help you! Your precious advice will be appreciated and we are very thankful for it!
1.If you have an urgent question, you can contact our slaes via trade manager of alibaba or email to them!
2.If you have a technic problem, please contact with the online service and they will help you deliver it to the technology department, we will give our solutions once they have it after experiments and discusions.
Hefei Quickly Electric Co., Ltd is a company full of power and thought. With decades of studying on the infrared radiation, we find that heating by infrared light can help us improve the efficiency of producing and save a lot of energy we used to losing. It directly produce a same wavelength as the heated objects so as to ensure the mass use of energy. It breaks the tranditional heating ways and quickly used in every heating process these years. It has been a trend of using it to replace the original heating ways!
Less loss of energy will make a great profit for manufacture and factories!
What do you think?
